Pemtron ATHENA 3D AOI SMT LINE AOI 3D Automated Optical Inspection System AOI Equipment AOI Machine For SMT Machine Line SMT Assembly Line

Pemtron ATHENA 3D AOI SMT LINE AOI For SMT Machine Line

Model:Pemtron ATHENA

Camera:10MP/12MP

Resolution(10MP):10um/15um/18um

Resolution(12MP):10um/15um

Inspect Speed(10MP):19cm/sec-41cm/sec-59cm/sec

Inspect Speed(12MP):28.34cm/sec-57.31cm/sec

FOV (Field Of View)(10MP):33×30mm/49×45mm/59×54mm

FOV (Field Of View)(12MP):41×30mm /61×46mm

Height Range:0-5.5mm(option27mm)

Height Accuracy:±3%

Inspection Size(Standard):Min.50×50mm(2×2inch)/Max.330×330mm(13×13inch)

Inspection Size(Large):Min.50×50mm(2×2inch)/Max.510×510mm(20×20inch)

Thickness:0.4～7mm

Top Clearance:50mm

Electrical requirements:200～240Vac,1Phase,50/60Hz

Power Consumption:3.5KW(16.0AMax@220AC)

Machine Dimension(Standard):1050×1295×1550mm(41×51×61inch)/About900kg(1984lb)

Machine Dimension(Large Type):1230×1500×1550mm(48×59×61inch)/About1050kg(2315lb)

Product Description

Pemtron ATHENA 3D AOI SMT LINE AOI 3D Automated Optical Inspection System AOI Equipment AOI Machine For SMT Machine Line SMT Assembly Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

Pemtron ATHENA 3D AOI SMT LINE AOI Technical Parameters :

Model			Pemtron ATHENA
Camera			10MP			12MP
Resolution			10um	15um	18um	10um	15um
Inspect Speed			19cm/sec	41cm/sec	59cm/sec	28.34cm/sec	57.31cm/sec
FOV (Field Of View)			33×30mm	49×45mm	59×54mm	41×30mm	61×46mm
Height Range			0-5.5mm(option27mm)
Height Accuracy			±3%
PCB Specification	Inspection Size	Standard	Min.50×50mm(2×2inch) Max.330×330mm(13×13inch)
		Large	Min.50×50mm(2×2inch) Max.510×510mm(20×20inch)
	Thickness		0.4～7mm
	Top Clearance		50mm
Electrical requirements			200～240Vac,1Phase,50/60Hz
Power Consumption			3.5KW(16.0AMax@220AC)
Machine	WxDXH/Weight (Standard)		1050×1295×1550mm(41×51×61inch)/About900kg(1984lb)
Dimension	WxDXH/Weight (Large Type)		1230×1500×1550mm(48×59×61inch)/About1050kg(2315lb)
*Specifications subject to change without notice.

Pemtron ATHENA 3D AOI SMT LINE AOI Details:

World's Best High Speed Measurement and Inspection Capability

As applying 12-way and 16-way projectors including the existing 8-way projectors with the basis of advanced technology,ATHENA minimizes errors caused by shadow effects for 3D measurement of all models and simultaneously performs 100%2D &3D inspectionin all FOV areas.This makes it possible to achieve a near-perfect detection while significantly reducing false calls

PEMTRON new head type has been upgraded from the existing head for 3D formatior that is identical to the real image and more stable based on the accumulated technology for decades.

■Simple Head Composition

▶More Space,Convenient Maintenance,Concise Assembly and Setting

■More advanced 3D technology

More stable and accurate 3D realization by installing additional projectors

8way(option 12way)/12way(option 16way)

▶Formation of Chip 3D among Dense Components and Narrow Parts

▶3D Formation Same as Real Image

■Improved Repeatability

▶Accurate 3D makes repeatability more reliable.

Pemtron ATHENA 3D AOI SMT LINE AOI Picture Show:

EXHIBITION:

SMT LINE:
