SMT Placement Solution Smd Mounting Machine JUKI FX-3RA High Speed Modular Mounter Led Pick and Place Machine For SMT Assembly Line SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
JUKI FX-3RA High Speed Modular Mounter Technical Parameters :
Modle Name
FX-3RAL
FX-3RAXL
Board Size
M size
330 x 250mm
-
L size
410 x 360mm
-
L-Wide size*1(Option)
-
510 x 360mm
XL size
800×360mm
800×560mm
Component height
6mm
Component size
Laser recognition
0402(01005) ~ 33.5mm
Placement speed
Optimum
0.040Sec. / chip(90,000CPH)*2
IPC9850
66,000CPH*2
Placement accuracy
Laser recognition
±0.05mm(±3σ)
Component loading quantity
Max.240 in case of 8mm tape(on a Electric double tape feeder)
Power Supply
200 to 415 VAC, 3-phase
Apparent Power
Max .7.5kVA/Max .8.5kVA
Operating air Power
0.5±0.05MPa
Air consumption
150L/min
Equipment Size (mm)
L size
2,650mm×1,650mm×1,530mm
L-Wide size
2,880mm×1,650mm×1,530mm
XL size
2,880mm×1,850mm×1,530mm
Mass(Kg)
L、L-Wide size
Approx. 3,500Kg
XL size
Approx. 3,750Kg
*1 L-Wide size , Applicability to long PWB is optional.
JUKI FX-3RA High Speed Modular Mounter Details:
FX-3RA
High Speed Modular Mounter
Refined high-speed, high-precision technology.
Developed under JUKI's "3E EVOLUTION" concept, the ever evolving FX series has been redesigned for ease of use, efficiency, cost effectiveness and increased expandability and compatibility. Using new, highly efficient linear servomotors, lightening and stiffening the head unit, and reviewing the placement sequence allow for an effective tact of 0.040 s/chip (90,000 CPH) (optimum conditions).
The JUKI FX-3RA SMT Pick and Place machine offers a precise and efficient solution for high-speed electronic component placement. With its advanced technology and industry-leading accuracy, this machine streamlines production processes and maximizes productivity. Increase your manufacturing capabilities with the JUKI FX-3RA. Improve manufacturing efficiency and accuracy with the JUKI FX-3RA. This industry-leading machine offers advanced technology and high-speed placement for electronic components, streamlining production processes and increasing productivity. With its precise capabilities, the JUKI FX-3RA is the ideal solution for increased manufacturing capabilities. Maximize your manufacturing capabilities with the JUKI FX-3RA SMT Pick and Place machine. This industry-leading machine boasts advanced technology and high-speed placement for electronic components, allowing for streamlined production processes and increased productivity. With its precise and efficient capabilities, the JUKI FX-3RA is the perfect solution for improved manufacturing efficiency and accuracy. Trust in this machine to elevate your production processes and meet the demands of the electronic industry.
Feature:
1.0402mm(01005 inch) ~ 33.5mm×33.5mm
2.Laser recognition : ±0.05mm(±3σ)
3.On-the-fly centering using integrated laser
4.2 stations, 4 gantries, 4 placement heads, 24 nozzles
5.Linear servo motor XY drive with full closed-loop control
6.Holds up to 240 components
7.Electrical or mechanical feeder trolley
JUKI FX-3RA High Speed Modular Mounter Picture Show:
EXHIBITION:
SMT LINE:
