SMT Placement Solution Smd Mounting Machine JUKI KE-2010 High Speed Chip Shooter Led Pick and Place Machine For SMT Assembly Line SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
JUKI KE-2010 High Speed Chip Shooter Technical Parameters :
Modle Name:
KE-2010M
Board size:
50×30~330×250mm
PWB Thickness:
0.4~4mm
Component Size:
0402~20mm square components or 26.5×11mm IC/ BGA / CSP
Mounting speed:
1,1000CPH
Mounting accuracy:
±0.05mm/±0.03mm(image recognition)
Feeder Capacity:
80ea (up to 100ea using MTC)
feeders species:
Tape (8mm, 12mm, 16mm, 24mm,32mm, 44mm, 56mm, 72mm) Rod / Bulk / Tray
Power Supply:
3-phase 220V ~ 380V Frequency 50 / 60Hz
Apparent Power:
Max .3.0kVA
Operation Air Preasure:
0.5±0.5Mpa
Air Consumption:
Max .230L/min
Mass(Kg):
Approx. 1,400Kg
Equipment Size (W×D×H):
1,300x1,471x1,550mm
JUKI KE-2010 High Speed Chip Shooter Details:
JUKI KE-2010 Pick and Place Machine a mid-speed placement machine, generally 2000-2008 equipment, laser patch head x 1 (4 nozzles) & high-resolution visual placement head x 1 (1 nozzle) .JUKI2010 modified can be mounted 1.2 m LED light board. JUKI KE-2010 Chip mounting speed is up to 11000CPH and applicable for 0402 ~ 20mm components. Applicable components - Tape (8mm, 12mm, 16mm, 24mm, 32mm, 44mm, 56mm, 72mm) Rod / Bulk / Tray.
JUKI KE-2010 High Speed Chip Shooter Picture Show:
EXHIBITION:
SMT LINE:
