SMT Placement Solution Smd Mounting Machine JUKI KE-760 High Speed Chip Mounter Led Pick and Place Machine For SMT Assembly Line SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
JUKI KE-760 High Speed Chip Mounter Technical Parameters :
Modle
KE-760
Head
2Head
Placement Speed:
7,000CPH(0.32SEC/CHP,1.8 / sec QFP)
Angle Accuracy
0.001 degree.
Placement Accuracy:
CHIP
±30μm@Cpk≥1.0
QFP
±90μm@Cpk≥1.0
Component Range:
0402 ~ 50 × 50mm
Board Dimension:
Min.
50(L)x30(W)
Max.
330(L)x250(W)
Feeder Capacity(8mmbasis):
80ea(Multilayer pallet feeder up to 100ea after use)
feeders species:
8mm, 12mm, 16mm 32mm 32mm to 3244mm, 56mm tape feeders, tray
Utility:
Power:
Single-phase,AC200
50/60Hz
Max 2.5KVA
Air Consumption:
0.5~0.7MPa(5~7kgf/cm2)
150NL/min
Mass(Kg):
Approx. 1,150Kg
Equipment Size (mm):
1,400(L) x 1,300(D) x 1,551(H)
JUKI KE-760 High Speed Chip Mounter Details:
JUKI’s
JUKI KE-760 High Speed Chip Mounter Picture Show:
EXHIBITION:
SMT LINE:
