SMT Placement Solution Smd Mounting Machine JUKI JX-350 SMT Flexible LED Mounter Led Pick and Place Machine For SMT Assembly Line SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
JUKI JX-350 SMT Flexible LED Mounter Technical Parameters :
Modle
JX-350
Board size
1time clamping
650×36Omm
2time clamping
1,200×360mm
3time clamping*
1,500×360mm
Component height
6mm/12mm
Component size
0603(0201) ~ 33.5mm
Placement speed (chip)
Optimum
32,000CPH
IPC9850
21,000CPH
Placement accuracy
±0.05mm (Cpk ≥1)
Feeder inputs
Front-side fixed mechanical
feeder bank(Standard)
Max.40 in case of 8mm tape
Front+rear-side fixed mechanical
feeder bank*1
Max.80
Front+rear-side fixed electrical
feeder bank*1
Max.160*2
Power Supply
AC200~415V(3-Phase)
Apparent Power
Max .2.2kVA
Operation Air Preasure
0.5±0.5Mpa
Air Consumption
50L/min
Mass(Kg)
Approx. 1,670Kg
Equipment Size (mm)
1,920x1,580x1,500mm
JUKI JX-350 SMT Flexible LED Mounter Details:
Product description
JUKI’s JX-350 offers high flexibility and quality presented in a compact design while maintaining an attractive low price. This model handles long printed circuit boards up to 1.50 meter and is especially suitable for cost-efficient LED assemblage. On top of that the incorporated laser technology enables a highly accurate placement of diffusion lenses due to the recognition technology which identifies the main orientation of the lens.
Long Board Production up to 1,500 mm
This model is capable of 1,200 mm long PWB production as standard. Long board production up to 1,500 mm is available. This is the best long board size on the market. Long board production includes several clamping steps. Placements on the placement area are optimized in order to enhance placement speed and productivity significantly.
High Flexibility
Alternate pick by offset nozzles achieves high-speed placement for large components up to 25 mm diameter. Offset nozzles enable pick, recognition and placement of 6 diffusion lenses or large components, up to 25 mm diameter, in one pass. Reduced head unit movement improves productivity significantly.
High Productivity
The placement rate of 32,000 CPH is achieved due to a lighter crossbar and a revised steering of the head, therefore attaining a tempo increase of 18 % as opposed to the latest model. An independent control of each individual Z- and Theta-Axis of the head allows superior flexibility, accuracy and redundancy while achieving high-precision placement angles.
JUKI JX-350 SMT Flexible LED Mounter Picture Show:
EXHIBITION:
SMT LINE:
