YAMAHA YRi-V 3D AOI SMT LINE AOI 3D Automated Optical Inspection Machine
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
YAMAHA YRi-V 3D AOI SMT LINE AOI Technical Parameters :
Model
YRi-V
YRi-V TypeHS
Number of pixels
12 megapixels
25 megapixels
Resolution
12μm
7μm
5μm
7μm
5μm
3D inspection speed¹)
56.8cm²/s
19.6cm²/s
10.1cm²/s
30.5cm²/s
16.2 cm²/s
3D projector
8 projector/4 projector
3D measuring height²)
Max.25mm
Number of pixels of the 4-angle camera
20 megapixels
Applicable PCB
L50xW50mm (min.)～L610xW610mm (max.)⁴
L760mm long length PCBs available (option)
PCB height that can be carried in
Top:45mm,bottom:85mm⁴)
Top:45mm,bottom:85mm3)4)
Power supply
Air supply source
0.45MPa or more,in clean,dry state
External dimension
L1,252xW1,497xH1,614mm
Weight
1,480kg
1,430kg
1) Under our optimized conditions during four projections.
2) Under our optimized conditions.
3) When 3D laser option is selected, the height of the component transported with the PCB will be limited to “33 mm high to the upper surface.”
4) For single-lane use.
For out-of-specification PCBs, consult your sales representative.
YAMAHA YRi-V 3D AOI SMT LINE AOI Details:
The YRi-V AOI features a newly developed inspection head equipped with a high-speed, high-resolution camera, extending existing 12μm and 7μm resolution lenses with a new 5μm resolution lens. High-precision 8-direction 3-D projector offers greater component inspection compatibility thanks to new coaxial lighting, improving measurement accuracy and range by 100% compared to current models and high-precision measurement now possible for up to 25mm in height. Revised conveyors handle more compatible PCB lengths. AI-powered deep learning simplifies, automates and lowers skill requirements for inspection data creation, conversion, tuning, etc. Offers greater detection capability for 0201 size (0.25mm x 0.125mm) components and mirror-glossed components.
Features
1.High-speed 3D inspection 56.8cm²/sec (under optimum conditions)
2.Super high-accuracy 3D inspections8-way projector
3.4-way oblique imaging inspections
4.20Megapixels 4-angle camera
5.Super high-resolution 5μm/coaxial lighting
