MERAIF MF-Q350 Automatic PCB Cutting Machine Board Cutter Machine PCB Separator PCB Board Cutting Machine

MERAIF MF-Q350 PCBA Cutting Machine

Model:MF-Q350

Effective cutting size:340*360MM

Cutting function:Lines, points, arcs, circles, etc.

Machining table:Daul countertop

Cutting precision:±0.05MM

Repeatable positioning accuracy:±0.015MM

Maximum movement speed:X,Y1,Y2:1000mm/s,Z:800mm/s

Applicable milling cutter size:0.8~3.0MM

Host power supply specifications:AC220V 50/60HZ(single)

Cutting host size:L*W*H(1180mm*1180mm*1350mm)

Cutting machine weight:800kg

Size of dust collector:L665mm*W635mm*H1610mm

Dust collector weight:155kg
