SMT Printer Machine GDK Galaxy SMT Stencil Printer Automatic Screen Printing Machine SMT Solder Paste Printer For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
GDK Galaxy Fully Automatic SMT Stencil Printer Technical Parameters :
|
Model |
GDK Galaxy |
|
PCB parameters |
|
|
Max. board size(X x Y) |
450x350mm |
|
Mini. board size(X x Y) |
50x50mm |
|
PCB thickness |
0.4~6mm |
|
Warpage |
≤1%Diagonal |
|
Max. board weight |
3Kg |
|
Board margin gap |
Configuration to 3mm |
|
Max. bottom gap |
20mm |
|
Transfer speed |
1500mm/s(Max) |
|
Transfer height from the ground |
900±40mm |
|
Transfer orbit direction |
L-R,R-L,L-L,R-R |
|
Transfer mode |
One stage orbit |
|
PCB damping method |
Programmable flexible side pressure + Adaptive PCB board thickness + Edge lock base clamp
(Optional: 1. Multipoint partial vacuum of the bottom; 2. Edge locking and substrate clamping)
|
|
Support method |
Magnetic thimble, Equal high block,etc.(Optional:1.Vacuum Chamber;2.Special workpiece fixture) |
|
Printing parameters |
|
|
Printing head |
Floating intelligent printing head (two independent direct connected motors) |
|
Template frame size |
470x370~737x737mm |
|
Maximum printing area(X x Y) |
450x350mm |
|
Squeegee type |
Steel scraper/Glue scraper(Angel 45°/50°/60° matching the printing process) |
|
Squeegee length |
300mm(optional with length of 200mm-500mm) |
|
Squeegee height |
65±1mm |
|
Squeegee thickness |
0.25mm Diamond-like carbon coating |
|
Printing mode |
Single or double scraper printing |
|
Demoulding length |
0.02-12 mm |
|
Printing speed |
0 ~ 200 mm/s |
|
Printing pressure |
0.5-10Kg |
|
Printing stroke |
±200 mm (From the center) |
|
Cleaning parameters |
|
|
Cleaning mode |
1. Drip cleaning system; 2. Dry, wet and vacuum modes |
|
Length of cleaning and wiping board |
380mm(optional with 300mm, 450mm, 500mm) |
|
Image parameters |
|
|
Field of view |
8x6mm |
|
Platform adjustment range |
X:±5.0mm,Y:±7.0mm,θ:±2.0° |
|
Benchmark point type |
Standard shape benchmark point(SMEMA standard),solder pad/openings |
|
Camera system |
Independent camera,upwards/downwards imaging vision system |
|
Performance parameters |
|
|
Repetition image calibration |
±10.0μm @6 σ,Cpk ≥ 2.0 |
|
Repetition printing |
±20.0μm @6 σ,Cpk ≥ 2.0 |
|
Cycle time |
<7s(Exclude printing and cleaning) |
|
Product changeover |
<5mins |
|
Equipment |
|
|
Power requirements |
AC220V±10%,50/60HZ,15A |
|
Compressed air requirements |
4~6Kg/cm2 |
|
Operating system |
WIN7 |
|
External dimension |
1,152(L) x 1,415(W) x 1,540(H)mm(Without light,monitor and keyboard) |
|
Machine weight |
Appro.1000Kg |
Fully Automatic Visual Solder Paste Scereen Printer/ SMT Stencil Printer (Galaxy)
Simple and reliable structure, accurate positioning and easy to adjust, It can quickly achieve different thickness of the PCB board PIN pin height adjustment of the automatic adjustment. The spray nozzle makes the cleaning liquid evenly sprinkled on the wiping paper, and the arc-shaped rubber wipe board is soft, antiwear and antirust, clean thoroughly bidirectionally.
GDK Galaxy Fully Automatic SMT Stencil Printer Picture Show:
Exhibition:
SMT LINE:
