SMT Printer Machine GKG PMAXII SMT Screen Printer Automatic Stencil Printer Machine SMT Solder Paste Printer For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
GKG PMAXII Fully Automatic SMT Screen Printer Technical Parameters :
Model
PMAXII
Item
Performance
Machine Alignement capability
±25 microns
Core Cycle Time
< 25 secs (Excluding printing & cleaning)
Product Changeover time
5 mins
New Product Setup Time
10 mins
Maximum Size (LxW)
1220x 800 mm
Minimum Size (LxW)
100x 65 mm
Thickness
0.4~10 mm
PCB Thickness Adjustment
Auto leveling
PCB Support Methods
Magnetic pins, support blocks, auto table adjustment
PCB Clamping Methods
Retractable top clamp & motor controlled side clamp
PCB Max. Weight
10 kg
PCB Edge Clearance
3.5 mm
PCB Bottom Clearance
23 mm
PCB Warpage
Max. 1% diagonally
Conveyor Direction
L > R, R > L, R > R, L > L (Software controlled)
Conveyor Height
Standard is 900mm ±20mm (If need any higher need to include footage support)
Conveyor Speed
Max. 1500 mm/sec
Conveyor Width Adjustment
Auto
Stencil Frame Size (LxW)
Adjustable, 737x 737 mm~1500 mm x 1250 mm
Print Head
Arc shape beam with 2 independent double linear guide motorized heads
Printing Table
Single / Double (Software select)
Adjustment Range
X: ±20 mm; Y: ±20 mm; Θ: ±2°
Squeegee Size
Metal: Two pair = 850mm & 1,250mm
Squeegee Pressure
0 - 30 kgs (Programmable)
Squeegee Speed
5 - 150 mm/sec
Squeegee Angle
Std. 60°, Option 45°, 50°, 55°
Cleaning System
Auto wet/dry/vacuum combination (User edit)
Vision Method
Single camera simultaneously Look Up/Look Down
Field of View (FOV)
8 mm x 6 mm
Fiducial Type
Circle, triangle, square, diamond, cross
Fiducial Size
0.5 ~ 4.0 mm
20 Inspection
100 windows to inspect missing, insufficient (Std.)
Hardware
LCD Monitor, Mouse & keyboard
Operating System (OS)
Window 10 or higher
Control Method
Industrial PC controlled
I/O Interface
SMEMA Standard
Power Supply
AC 220 V ±10%, 50/60 Hz, single phase
Air Supply
4 ~ 6 Kgf/cm2
Power Consumption
3 KW
Dimension (Exclude signal lamp)
2,020 (W) x 1,740 (D) x 1,524 (H) mm
Machine Weight
Approx.1800 Kg
GKG PMAXII Fully Automatic SMT Screen Printer Details:
PMAXII
Screen-Printer
Large scale printers such as the PMAXII from JUKI made by GKG are designed for three-shift operation and a long service life with low maintenance requirements. The machine table and squeegee carrier are cast, not welded. Therefore guaranteeing high torsion resistance and ensuring the print accuracy will remain unchanged for years. JUKI’s PMAXII handles large circuit boards of sizes up to 1,220 × 800 mm and has notably specialised on LED-applications.
Long-Lasting Accuracy
The machine table and squeegee carrier are cast, not welded, therefore guaranteeing a high torsion resistance and the print accuracy will remain unchanged for years.
High Flexibility
PMAXII and JUKI Pick and Place machines as well as JUKI Reflow Soldering Ovens enable needs-based, individual SMT line solutions.
Optimised Operation and Maintenance
Straightforward Windows-based operator software enables fast initial training and swift programme creation. A programme change takes about two minutes while a new programme compilation is completed within approximately ten minutes. Large covers and service doors allow for easy access to all assemblies throughout the whole process.
