SMT Printer Machine GKG GT++ SMT Stencil Printer Automatic Screen Printing Machine SMT Solder Paste Printer For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
GKG GT++ Fully Automatic SMT Stencil Printer Technical Parameters :
|
Model |
GT++ |
|
Max PCB Size |
510x510mm |
|
Min PCB size |
50x50mm |
|
PCB thickness |
0.4-6mm |
|
Max board weight |
5kg |
|
Transport height |
900±40mm |
|
Board edge gap |
2.5mm |
|
Board height |
23mm |
|
Transport direction |
L-R,R-L |
|
Transport speed |
max 1500mm/s, program control |
|
Transport method |
One stage |
|
PCB positioning (support method) |
Magnetic pin/support block/auto up-down table |
|
PCB clamping system |
Patented over the top clamping |
|
|
Side clamping |
|
|
Adsorption function |
|
Print snap-off |
0-20mm |
|
Print mode |
one/twice |
|
Print Speed |
10-200mm/sec |
|
Print Mode |
One /Twice |
|
Squeegee Type |
Rubber /steel Squeegee Blade(Angle 45°/55°/60°) |
|
Print pressure |
0.5-10kg |
|
Template fram size |
470*370mm~737*737mm(20-40thickness) |
|
Cleaning System |
Droops of rain type cleaning system |
|
|
Dry, wet vacuum three modes |
|
|
Back and forth cleaning |
|
CCD FOV |
10x8mm |
|
Fiducial mark types |
Standard Fiducial mark shape |
|
|
Pad |
|
|
Hole |
|
Camera system |
Look up/down optics structure |
|
|
CCD digital camera |
|
|
Geometry pattern match |
|
Repeat position accuracy |
±12.5um@6,CPK≥2.0 |
|
Print accuracy |
±18um@6,CPK≥2.0 |
|
Print cycle time |
＜7.5 sec |
|
Power supply |
AC:220±10%,50/60HZ, 3.0KW |
|
Air pressure |
4~6 kgf/cm² |
|
Air consumption |
around 5L/min |
|
Operating temperature |
-20℃~+45℃ |
|
Operating humidity |
30%~60% |
|
Machine Dimensions (without tower light) |
1,240(L) x 1,410(W) x 1,500 (H)mm |
|
Machine Weight |
Approx:1100Kg |
|
Based on the third party test system(CTQ) verify the actual solder paste printing position repeat precision |
|
GKG GT++ Fully Automatic SMT Stencil Printer Details:
GT++ is high accuracy and high stability of the fully automatic printing machine vision,GKG followed in SMT industry is the development trend of production of a new generation of fully automatic printing machine with the international leading technology synchronous vision, visual processing of high resolution, high precision of the transmission system.
GKG GT++ Fully Automatic SMT Stencil Printer Picture Show:
