SMT Printer Machine GKG G9+ SMT Stencil Printer Automatic Screen Printing Machine SMT Solder Paste Printer For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
GKG G9+ Fully Automatic SMT Stencil Printer Technical Parameters :
|
Model |
G9+ |
|
Maximum board size |
450*340mm |
|
Minimum board size |
50*50mm |
|
Board thickness |
0.4~6mm |
|
Maximum board weight |
3Kg |
|
Board edge clearance |
2.5mm |
|
Board height |
15mm |
|
Transport height |
900±40mm |
|
Transport speed |
1500mm/s(Max)Program Control |
|
Transport direction |
One stage |
|
Board clamp |
Plandover the top damping |
|
|
Side clamping |
|
|
Adsorption function |
|
Support System |
Magnetic Pin |
|
|
Support Block |
|
|
Manual up-down table |
|
Printing Snap-off |
0-20mm |
|
Print Mode |
One/Twice |
|
queegee Type |
bber/Steel Squeegee Blade(angle 45/55/60) |
|
Print Speed |
10~200mm/sec |
|
Print Pressure |
0.5~10Kg |
|
The template frame size |
470*370mm~737*737mm(20mm ~ 40mm) |
|
Cleaning System |
Drops of rain type cleaning system |
|
|
Reinforced Vacuum absorption |
|
|
Dry, Wet Vacuum three modes |
|
|
Back and forth cleaning |
|
CCD FOV |
10*8mm |
|
Fiducial mark types |
Standard shape datum, custom images |
|
|
Pad |
|
|
Hole |
|
Camera System |
Look up/down optics structure |
|
|
CCDdigital camera |
|
|
Geometry pattem match |
|
Repeat PostionAccuray |
±12.5um@6σ，CPK≥2.0 |
|
Print Accuracy |
±18um@6σ，CPK≥2.0 |
|
Based on the third party test system(CTQ)Verify the actual solder paste printingposition repeat precision |
|
|
Printing cycle |
< 7.5sec |
|
Power Source |
AC:220±10% ,50/60HZ,2.5KW |
|
Air Pressure |
4~6 Kgf/cm2 |
|
Air Consumption |
About 5L/min |
|
Operating Temperature |
–20C~+45C |
|
Operating Humidity |
30%~60% |
|
Machine dimensions |
1530(H)×1172(L)×1385(W)mm |
|
Machine Weight |
Approx:1000Kg |
GKG G9+ Fully Automatic SMT Stencil Printer Details:
GKG G9+ SMT Stencil Printer, Fully Automatic tin paste printing machine is a high-end model for SMT high-end application, which can satisfy the printing process requirements of 03015,0.25 pitch, high precision and high speed.
G9+ is high accuracy and high stability of the fully automatic printing machine vision,GKG followed in SMT industry is the development trend of production of a new generation of fully automatic printing machine with the international leading technology synchronous vision, visual processing of high resolution, high precision of the transmission system, suspension adaptive scraper.
