SMT Printer Machine GKG G5 SMT Stencil Printer Automatic Screen Printing Machine SMT Solder Paste Printer For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
GKG G5 Fully Automatic SMT Stencil Printer Technical Parameters :
GKG G5 Fully Automatic SMT Stencil Printer Details:
Machine performance
Repeat position accuracy
±0.01mm
Print accuracy
±0.025mm
NCP-CT
7.5s
HCP-CT
19s/pcs
Process CT
5min
Change line CT
3min
Substrate processing parameter
Max board size
400*340mm (Option:530*340mm)
Min board size
50*50mm
Board thickness
0.4~6mm
Camera mechanical range
528*340mm
Max board weight
3kg
Board adge clearance
2.5mm
Board height
15mm
Transport speed
900±40mm
(Max) Transport speed
1500mm/s max
Transport direction
One stage
Transmission direction
Left to right
Right to left
In and out the same
Support system
Magnetic pin
Support block
Manual up-down table
Board damp
Automatic the top clamping
Side clamping
Adsorption function
Printing parameters
Print speed
10-200mm/s
Printing pressure
0.5~10kg
Print mode
One/twice
Queegee type
Rubber, squeegee blade (angle 45/55/60)
Snap- off
0-20mm
Sanp speed
0-20mm/s
The template frame size
470*370mm-737*737mm (thickness 20-40mm)
Positioning mode of steel mesh
Automatic Y-direction positioning
Cleaning parameteres
Cleaning method
Dry, wet, vaccum, three modes
Cleaning system
Up drip type
Cleaning stroke
Automatic generation
Cleaning position
Post cleaning
Cleaning speed
10-200mm/s
Cleaning fluid consumption
Auto/Manually adjustable
Cleaning pater consumption
Auto/Manually adjustable
Vision parameters
CCD FOV
10*8mm
Camera type
130 thousand CCD digital camera
Camera system
Lock up/down optic structure
Camera cycle time
300ms
Fiducial mark types
Standard fiducial mark shape
Round, square, diamond, cross
Pad and profile
Mark size
0.5-5mm
Mark number
Max. 4pcs
Stay away number
Max. 1pc
Machine parameter
Power source
AC 220 ±10%, 50/60Hz 2.2KW
Air pressure
4~6kgf/cm²
Air consumption
~5L/min
Operating temperature
-20°C~+45°C
Working invironment humidity
30%-60%
Machine dimension (without flower light)
1140(L)*1364(W)*1404(H)mm
Machine weight
Appr 900kg
Equipment load bearing requirements
650kg/m²
G5 is a high-precision and high-stability fully automatic visual printing machine, high-resolution visual processing, high-precision transmission system, suspended automatic adaptive scraper, precise board positioning processing and smart screen frame clamping structure, compact structure , both accuracy and high flexibility, precise printing required functions.
1. GKG dedicated manual adjustment pre-lift platform: simple and reliable structure, low cost, convenient manual adjustment, can quickly realize the adjustment of the PIN pin jacking height of PCB boards with different thicknesses.
2. Image and optical path system: The uniform ring light and high-brightness coaxial light of the brand-new optical path system, together with the brightness function that can be adjusted steplessly, make all types of Mark points can be well recognized (including uneven ones) Mark point), suitable for tin-plated, copper-plated, gold-plated, HASL, FPC and other types of PCBs of different colors.
3. Scraper system: Slide rail type scraper system, which improves the running stability and long service life.
4. Cleaning system: The new type of wiping rubber strip ensures full contact with the stencil, increases the vacuum suction to ensure that the residual solder paste in the mesh is vigorously eliminated, and truly realizes the effective automatic cleaning function, three cleaning modes of dry and wet vacuum , the software can set the cleaning mode and cleaning paper length at will.
