MERAIF D1 2D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 2D AOI SMT AOI Machine AOI Machine In SMT

MERAIF D1 2D AOI Offline AOI For SMT Machine Line

Model:D1

PCB size:50×50mm-250×350mm/400×400mm

Thickness:0.5mm-6mm

Illuminant:High-uniform hole-opening foreground LED cold white light

Camera:12MP/25MP color face array high-speed industrial camera

FOV&resolution ratio:85um@250×350mm/115um@400×400mm

Component detection:Missing parts of plug-in components,anti-parts,multiple insert,skew,small particle characteristic wrong parts,screen mark text recognition,bar code scanning,etc

Algorithm:Deep neural network algorithm,image contrast,color contrast,template matching,etc

Function:Remote control,remote assistance,CAD,and custom model training

Indicator:24-inch FHD indicator display

Case size and weight:773×902×1422mm,Approx.150KG/969×1072×1422mm,Approx.200KG

Supply:AC220V,power rating 0.5KVA 0.4-0.6Mpa

Ambient temperature:Temperature: 10-45ºC, humidity: 30-85%RH

Product Description

MERAIF D1 2D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 2D AOI SMT AOI Machine AOI Machine In SMT

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

MERAIF D1 2D AOI Offline AOI Technical Parameters :

Model	D1	D1-W
PCB size	250×350mm	400×400mm
Thickness	0.5mm-6mm	0.5mm-6mm
Camera	12MP colour industrial camera	25MP colour industrial camera
Illuminant	High-uniform hole-opening foreground LED cold white light
FOV&Resolution ratio	85um@250×350mm	115um@400×400mm
Component detection	Missing parts of plug-in components,anti-parts,multiple insert,skew,small particle characteristic wrong parts,screen mark text recognition,bar code scanning,etc
Mixed board test	Mixed board production,support program automatically call
Algorithm	Deep neural network algorithm,image contrast,color contrast,template matching,OCR,etc
Function	Remote control,remote assistance,CAD,and custom model training
Indicator	24-inch FHD indicator display
Size and weight	773×902×1422mm,Approx.150KG	969×1072×1422mm,Approx.200KG
Power	AC220V,power rating 0.5KVA
Air supply	0.4-0.6Mpa
Ambient temperature	Temperature: 10-45ºC, humidity: 30-85%RH

MERAIF D1 2D AOI Offline AOI Details:

MERAIF D1 2D Optical Inspection System

AOI-D1 before furnace
Online PCBA plug-in optical inspection equipment

Detect defects such as missing, reverse and so on of DIP components, capture the board image in real time through a high-precision color industrial camera, process the image using a convolutional neural network algorithm, and intelligently determine if the components are defective.

Features

Minimalist programming,convenient operation, suppor tonline /offline

Multiple detection modes, adapted to the production

Detailed data test repor t, to suppor t SPC alarm

Can be matched with optional items, fast positioning isbad, to achieve

MERAIF D1 2D AOI Offline AOI Picture Show:
