MERAIF D4 3D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 3D AOI SMT AOI Machine AOI Machine In SMT Machine Line

MERAIF D4 3D AOI Online AOI For SMT Machine Line

Model:D4

PCB size:50×50mm-510×400mm

Thickness:0.5mm-6mm

Component height:Top 40mm, Bottom 40mm

Process side:3mm

Camera:5MP color face array high-speed industrial camera

FOV:10um#28mm*2lmm,20um#30mm*36mm

Coating detection:UV glue,more and less coating,splash,scatter

Algorithm:Deep neural network algorthms,image contrast,color contras,contour recognition,OCR,etc

Speed:0.3sec/FOV

Indicator:24-inch FHD indicator display

Case size and weight:1020×1308×1611mm(without three color lights)/Approx.760KG

Supply:AC 220V,power rating 2KVA 0.4-0.6Mpa

Ambient temperature:Temperature: 10-45ºC, humidity: 30-85%RH

Product Description

MERAIF D4 3D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 3D AOI SMT AOI Machine AOI Machine In SMT Machine Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

MERAIF D4 3D AOI Online AOI Technical Parameters :

Model	D4
PCB size	50×50mm-510×460mm
Thickness	0.5mm-6mm
Orbit altitude	900mm
Card load	≤3KG(leather belt) …
Component height	Top:40,Bottom:40mm
Process side	3mm
Camera	5MP color face array high-speed industrial camera …
Illuminant	UV+W light source
FOV	10um#28mm2lmm,20um#30mm36mm
Coating detection	UV glue,more and less coating,splash,scatter
Algorithm	Deep neural network algorthms,image contrast,color contras,contour recognition,OCR,etc
Speed	0.3sec/FOV
Functionr	Remote control,remote assistance,CAD,and custom model training
Track adjustment	Manual/automatic
Indicator	24-inch FHD indicator display
Case size and weight	1020×1308×1611mm(without three color lights)/Approx.760KG
Power	AC 220V,power rating 2KVA
Air supply	0.4-0.6Mpa
Ambient temperature	Temperature: 10-45ºC, humidity: 30-85%RH

MERAIF D4 3D AOI Online AOI Details:

MERAIF D4 3D Optical Inspection System

Single-sided coating AOI-D4
Online PCBA coating optical inspection equipment

Detect excess glue, insufficient glue and splash points caused by PCBA coating, capture the board image in real time through a high-precision color industrial camera, use the convolutional neural network algorithm to process the image, and intelligently judge the poor coating.

Features

The MES data statistics are traceable

The software supports fully automatic pipeline control

Detection area operation: copy, mirror, array

Simple erection and rapid transformation

Detection area editor:support round, rectangularpolygon

Auxiliary function: Mark positioning, glue width detectionstorage
