MERAIF S3 3D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 3D AOI SMT AOI Machine AOI Machine In SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
MERAIF S3 3D AOI Online Parameters :
Model
S3
S3-D
S3-L
PCB size
50×50mm-510×460mm
50×50mm-510×275mm/510×600mm
50×50mm-1200×460mm
Thickness
0.5mm-6mm
Component height
Top: 40mm, Bottom: 40mm
Process side
3mm
Camera
12MP color face array high-speed industrial camera
Illuminant
RGB+W four-color integrallight source+4-direction structured light projection unit
Resolution
10um/15um
FOV
10um@40*30mm/15um@60*45mm
Component detection
Cross feet,floating high,monument,missing parts,many pieces,flip,reverse,offset,damage,skew,foreign body,dirt,etc
Welding tin detection
Welder height,more tin,less tin,tin,empty welding,virtual welding,tin hole,etc
Barcode identification
1D/QR code identification/character recognition,etc
Mixed board test
Mixed board production,support program automatically call
Algorithm
Deep neural network algorithm,image contrast,color contrast,contour recognition,etc
Speed
0.55sec/FOV
Function
Remote control,remote assistance,gerber file import,and custom model training
Communication mode
Standard SMEMA interface
Host computer
Industrial control computer
Indicator
24-inch FHD indicator display
Gear
High-precision wire rod+servo motor
Track adjustment
Manual/automatic
Case size and weight
1120×1410×1611mm(Without three-color light),Approx.880KG
1120×1610×1611mm(Without three-color light),Approx.1100KG
2320×1410×1611mm(Without three-color light),Approx.1250KG
Power
AC 220V,power rating 2KVA
AC 220V,power rating 2.5KVA
AC220V,power rating 2.5KVA
Air supply
0.4-0.6Mpa
Ambient temperature
Temperature: 10-45ºC, humidity: 30-85%RH
MERAIF S3 3D AOI Online Details:
A Leading Global
Features
MERAIF S3 3D Optical Inspection System
Professional Visual Inspection Equipment Manufacturer
Traditional 2D AOl inspection couldn't find many types ofdefects by capturing 2D images.
Creative 3D digital projecting measurement technology is developed by Jutze to get the real contour data to dealwith SMD,Solder joints,Characters,and foreign material etc.,which overcomes the weakness of 2D AOI.
Accurate all-digital sinusoidal fringe phase,easy adjustable measurement range and accuracy;
Fast and high accurate whole area scanningwith wide height range;
User friendly interface with simple operation.
MERAIF S3 3D AOI Online Picture Show:
EXHIBITION:
SMT LINE:
