MERAIF SD 2D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 2D AOI SMT AOI Machine AOI Machine In SMT Line

MERAIF SD 2D AOI SMT Machine AOI For SMT Machine Line

Model:SD

PCB size:50×50mm-440×320mm

Thickness:0.5mm-5mm

Camera:5MP color face array high-speed industrial camera

FOV&resolution ratio:15um@36mm*30mm/10um@25mm*20mm

Indicator:24-inch FHD indicator display

Size and weight:900×1095×1320mm,Approx.300KG

Power:AC220V,power rating 1.6KVA

Air supply:0.4-0.6Mpa

Ambient temperature:Temperature: 10-45ºC, humidity: 30-85%RH

Product Description

MERAIF SD 2D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 2D AOI SMT AOI Machine AOI Machine In SMT Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

MERAIF SD 2D AOI Technical Parameters :

Model	SD
PCB size	50×50mm-440×320mm
Thickness	0.5mm-5mm
Camera	5MP color face array high-speed industrial camera
Illuminant	RGB LED ring light
FOV&resolution ratio	15um@36mm30mm/10um@25mm20mm
Component detection	More tin,less tin,even tin,missing parts,offset,skew,monument,reverse parts,extreme reverse,wrong parts,damaged
Algorithm	Deep neural network algorithm,image contrast,color contrast,template matching,etc
Function	Remote control,remote assistance,CAD,and custom model training
Track adjustment	Manual
Indicator	24-inch FHD indicator display
Size and weight	900×1095×1320mm,Approx.300KG
Power	AC220V,power rating 1.6KVA
Air supply	0.4-0.6Mpa
Ambient temperature	Temperature: 10-45ºC, humidity: 30-85%RH"

MERAIF SD 2D AOI Details:

Traditional 2D AOl inspection couldn't find many types ofdefects by capturing 2D images.

Creative 3D digital projecting measurement technology is developed by Jutze to get the real contour data to dealwith SMD,Solder joints,Characters,and foreign material etc.,which overcomes the weakness of 2D AOI.

Accurate all-digital sinusoidal fringe phase,easy adjustable measurement range and accuracy;

Fast and high accurate whole area scanningwith wide height range;

User friendly interface with simple operation.

Features

User-friendly software interface with easy operation
Precise fully digital sinusoidal interference phase
Easily adjustable measuring range and accuracy
Fast and high-precision scanning of the entire area with high height coverage
Representation of the complete component height in 3D
Displays the faulty locations in real time
Shadow-free display with four projectors and multi-angle lighting system
Small installation dimension: 1080 x 1300 x 1850mm
