MERAIF D4 3D AOI SMT Machine AOI Inspection Automated Optical Inspection SMT 3D AOI SMT AOI Machine AOI Machine In SMT Machine Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
MERAIF D4 3D AOI Technical Parameters :
MERAIF D4 3D AOI Details:
Features
MERAIF D4 3D AOI Picture Show:
EXHIBITION:
SMT LINE:
Model
D4
PCB size
50×50mm-510×460mm
Thickness
0.5mm-6mm
Orbit altitude
900mm
Card load
≤3KG(leather belt) …
Component height
Top:40,Bottom:40mm
Process side
3mm
Camera
5MP color face array high-speed industrial camera …
Illuminant
UV+W light source
FOV
10um#28mm*2lmm、20um#30mm*36mm
Coating detection
UV glue,more and less coating,splash,scatter
Algorithm
Deep neural network algorthms,image contrast,color contras,contour recognition,OCR,etc
Speed
0.3sec/FOV
Functionr
Remote control,remote assistance,CAD,and custom model training
Track adjustment
Manual/automatic
Indicator
24-inch FHD indicator display
Case size and weight
1020×1308×1611mm(without three color lights)/Approx.760KG
Power
AC 220V,power rating 2KVA
Air supply
0.4-0.6Mpa
Ambient temperature
Temperature: 10-45℃, humidity: 30-85%RH
