MIRTEC MV-6 OMNI 3D AOI SMT LINE AOI 2D Automated Optical Inspection System AOI Equipment AOI Machine For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
MIRTEC MV-6 OMNI 3D AOI SMT LINE AOI Technical Parameters:
Model:
MV-6E (OMNI)
PCB size:
50mm×50mm~480mm×460mm
High accuracy:
±3um
Max component height:
5mm
2D inspection items:
Missing parts, offset, skewed, tombstone, side-standing, overturned parts, polar opposites, wrong parts, damaged, soldered joints, false soldering, voids, OCR
3D inspection items:
Missing parts, height, position, more tin, less tin, missing solder, double chip, size, IC pin soldering, foreign matter, lifted parts, BGA lifted, tin crawling detection, etc.
FOV field of view:
58.56mm×58.56mm
3D detection speed:
0.80 s/FOV/4.260mm²/s
2D detection speed:
0.30 s/FOV/10, 716mm²/s
Lens:
Precise Telecentric Compound Lenses
Lighting system:
8-segment color lighting system
SPC:
Complete statistical software
PCB clearance:
45mm
PCB thickness:
0.5~5mm
Mini. measurement size:
03015
GPS:
Servo motor
Repeatability:
±10um
3D detection technology:
DVLP 8 groups of moiré stripe technology
Physical dimension(mm):
1080(W)×1470(D)1560(H)
Weight:
950KG
Gas source:
5KGf/cm²(0.5Mpa)
Power supply:
200-240VAC 50Hz/60Hz
MIRTEC MV-6 OMNI 3D AOI SMT LINE AOI Details:
MV-6 OMNI SeriesThe optimal 3D AOI to improve productivity
The world's best performance 3D AOI
- Non-blind spot digital 12 projection moiré 3D inspection technology
- Inspection for reflective objects, OCR, and crack defect precisely by 8 phase coaxial color light
- Smallest component inspection by ultra-high resolution camera and lens
- 18 mega pixel angled camera which has similar resolution with main camera
Precise Inspection: Best yield with combination of full 3D inspeciton, full 2D insepction and deep learning algorithm
Side-Viewer® : simultaneous 5-dimension inspection by using 18 mega pixel angled cameras
Intellisys® : Total process management system for improving productivity and achieving smart factory
AI Auto Programming : simple and easy programming by using IPC international standard library
The best performance at reasonable price
