Panasonic VM-102 Compact High Performance Placer Technical Parameters :
Model ID
VM102
PCB Dimensions (mm)*
L 50 × W 50 ~ L 330 × W 250 (Single-lane)
Electric Source
3-phase AC 200, 220, 380, 400, 420, 480 V 1.3 kVA
Pneumatic Source *
0.5 ~ 0.8 MPa 200 L /min (A.N.R.)
Dimensions (mm) *1 *2*3
W 830 × D 1,969 × H 1,500
Mass
1,910 kg(Front : Fixed supply unit, Rear : Fixed supply unit without cutting unit)
Component Supply Taping *4
Tape : 4 ~ 56 / 72 / 88 / 104 mm Max. 160 components (4/8 mm tape)
Component Supply Stick *5
Max. 40
Component Supply: Tray
Max. 20
Panasonic VM-102 Compact High Performance Placer Details:
The VM102 is based on the AM100 platform, but in a more compact form, leveraging the vaunted 14NH & up to four 20 slot feeder carts/160 8mm inputs, with an output of 32,100 CPH, accuracy of 30um in a 1.52m long / 3.14m footprint.
VM series models share common multi-recognition cameras, feeder carts, feeders, tray towers, and nozzles. These series can make up lines with common models or blended to offer maximum scalability and affordability. This series of platform is focused on Mid-sized board market suited to produce device, white-goods, medical and automotive products. The VM series is geared toward applications that require advanced capabilities at an affordable price.
Features:
▶The VM102 is based on the AM100 platform, but in a more compact form, leveraging the vaunted 14NH & up to four 20 slot feeder carts/160 8mm inputs, with an output of 32,100 CPH, accuracy of 30um in a 1.52m long / 3.14m footprint
▶High output of up to 32.1k CPH, as well as odd-form capability with stackable stick feed support, 100N placement force and Pin-in-Paste lighting
▶All-in-one placement head with range from 01005 ~ 150 x 25 x 28
▶Can support feeders on front only, or front and rear locations
▶Compatible with Panasonic intelligent feeders & nozzles
