FUJI NXT III Scalable Placement Platforms For SMT Machine Line

Model:NXT III

Applicable PCB size (LxW):48 x 48 mm to 305 x 610 mm (single conveyor)

Applicable PCB size (LxW):48 x 48 mm to 305 x 510 mm (double conveyor/single)

Applicable PCB size (LxW):48 x 48 mm to 305 x 280 mm (double conveyor/dual)

Part types:Up to 20 types of parts (calculated using 8 mm tape)

PCB loading time:For double conveyor: 0 sec (continuous operation)

PCB loading time:For single conveyor: 2.5 sec (transport between M3 III modules), 3.4 sec (transport between M6 III modules)

Module width:320 mm

Machine dimensions:L: 1295 mm (M3 III x 4, M6 III x 2) / 645 mm (M3 III x 2, M6 III)W: 1900.2 mm, H: 1476 mm

lntelligent feeders:Support for 4, 8, 12, 16, 24, 32, 44, 56, 72, 88, and 104 mm wide tape

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

SMT Placement Solution Smd Mounting Machine FUJI NXT III Scalable Placement Platforms Led Pick and Place Machine For SMT Assembly Line SMT Machine Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

FUJI NXT III Scalable Placement Platforms Technical Parameters :

Model

M3 III

M6 III

Applicable PCB size (LxW)

48 x 48 mm to 305 x 610 mm (single conveyor)
48 x 48 mm to 305 x 510 mm (double conveyor/single)
48 x 48 mm to 305 x 280 mm (double conveyor/dual)

48 x 48 mm to 610 x 610 mm (single conveyor)
48 x 48 mm to 610 x 510 mm (double conveyor/single)
48 x 48 mm to 610 x 280 mm (double conveyor/dual)

Part types

Up to 20 types of parts (calculated using 8 mm tape)

Up to 45 types of parts (calculated using 8 mm tape)

PCB loading time

For double conveyor: 0 sec (continuous operation)
For single conveyor: 2.5 sec (transport between M3 III modules), 3.4 sec (transport between M6 III modules)

Placement accuracy
(Fiducial mark standard)
* The placing accuracy is obtained from tests conducted by Fuji.

H24G : +/-0.025 mm (Standard mode) / +/-0.038 mm (Productivity priority mode) (3sigma) cpk≥1.00

V12/H12HS : +/-0.038 (+/-0.050) mm (3sigma) cpk≥1.00

H04S/H04SF : +/-0.040 mm (3sigma) cpk≥1.00

H08/H04 : +/-0.050 mm (3sigma) cpk≥1.00

H02/H01/G04 : +/-0.030 mm (3sigma) cpk≥1.00

H02F/G04F : +/-0.025 mm (3sigma) cpk≥1.00

GL : +/-0.100 mm (3sigma) cpk≥1.00



H24G : +/-0.025 mm (Standard mode) / +/-0.038 mm (Productivity priority mode) (3sigma) cpk≥1.00

V12/H12HS : +/-0.038 (+/-0.050) mm (3sigma) cpk≥1.00

H08M/H04S/H04SF : +/-0.040 mm (3sigma) cpk≥1.00

H08/H04/OF : +/-0.050 mm (3sigma) cpk≥1.00

H02/H01/G04 : +/-0.030 mm (3sigma) cpk≥1.00

H02F/G04F : +/-0.025 mm (3sigma) cpk≥1.00

GL : +/-0.100 mm (3sigma) cpk≥1.00

Productivity
* The throughput above is based on tests conducted at Fuji.

H24G : 37,500 cph (Productivity priority mode) / 35,000 cph (Standard mode)

V12 : 26,000 cph

H12HS : 24,500 cph

H08 : 11,500 cph

H04 : 6,500 cph

H04S : 9,500 cph

H04SF : 10,500 cph

H02 : 5,500 cph

H02F : 6,700 cph

H01 : 4,200 cph

G04 : 7,500 cph

G04F : 7,500 cph

GL : 16,363 dph (0.22 sec/dot)



H24G : 37,500 cph (Productivity priority mode) / 35,000 cph (Standard mode)

V12 : 26,000 cph

H12HS : 24,500 cph

H08M : 13,000 cph

H08 : 11,500 cph

H04 : 6,500 cph

H04S : 9,500 cph

H04SF : 10,500 cph

H02 : 5,500 cph

H02F : 6,700 cph

H01 : 4,200 cph

G04 : 7,500 cph

G04F : 7,500 cph

0F : 3,000 cph

GL : 16,363 dph (0.22 sec/dot)

Supported parts



H24G : 0201 to 5 x 5 mm Height : up to 2.0 mm

V12/H12HS : 0402 to 7.5 x 7.5 mm Height : up to 3.0 mm

H08M : 0603 to 45 x 45 mm Height : up to 13.0 mm

H08 : 0402 to 12 x 12 mm Height : up to 6.5 mm

H04 : 1608 to 38 x 38 mm Height : up to 9.5 mm

H04S/H04SF : 1608 to 38 x 38 mm Height : up to 6.5 mm

H02/H02F/H01/0F : 1608 to 74 x 74 mm (32 x 180 mm) Height : up to 25.4 mm

G04/G04F :0402 to 15 x 15 mm Height : up to 6.5 mm

Module width

320 mm

645 mm

Machine dimensions

L: 1295 mm (M3 III x 4, M6 III x 2) / 645 mm (M3 III x 2, M6 III)
W: 1900.2 mm, H: 1476 mm

Machine dimensions

DynaHead(DX)

Nozzle quantity

12

4

1

Throughput(cph)

25,000
Parts presence function ON: 24,000

11,000

4,700

Part size
(mm)

0402 (01005") to 7.5 x 7.5
Height:
Up to 3.0 mm

1608 (0603")
to 15 x 15
Height:
Up to 6.5 mm

1608 (0603")
to 74 x 74 (32 x 100)
Height:
Up to 25.4 mm

Placing accuracy
(Fiducial mark based referencing)

+/-0.038 (+/-0.050) mm (3σ) cpk≥1.00*
*+/-0.038 mm obtained with rectangular chip placement (high
accuracy tuning) under optimal conditions at Fuji.

+/-0.040 mm (3σ) cpk≥1.00

+/-0.030 mm (3σ) cpk≥1.00

Part presence
check

o

x

o

Parts
supply

Tape

o

o

o



Stick

x

o

o



Tray

x

o

o

Parts supply system

lntelligent feeders

Support for 4, 8, 12, 16, 24, 32, 44, 56, 72, 88, and 104 mm wide tape

Stick feeders

4 ≤ Part width ≤ 15 mm (6 ≤ Stick width ≤ 18 mm), 15 ≤ Part width ≤ 32 mm (18 ≤ Stick width ≤ 36 mm)

Trays

Applicable tray size: 135.9 x 322.6 mm (JEDEC standard) (Tray Unit-M)276 x 330 mm (Tray Unit- LT), 143 x 330 mm (Tray Unit-LTC)

Options

Tray feeders, PCU II (Pallet Change Unit), MCU (Module change unit), Engineering panel stand, FUJI CAMX Adapter, Nexim Software

*Contact Fuji or sales agents for specific operating conditions and detailed specifications.

FUJI NXT III Scalable Placement Platforms Details:

NXT III Scalable Placement Platforms

The NEW NXT III is a highly productive, multi-functional modular placing machine. Built for speed, it features a faster XY robot and tape feeders, as well as a new H24 head that achieves 35,000 chips per hour. The NXT III supports the smallest parts being used in mass production with extreme placing accuracy.

Features:

Improved Productivity
A faster XY robot and faster tape feeders, as well as a newly developed "flying vision" parts camera, mean increased placing ability for all part sizes and types.

The new H24G high-speed head achieves 37,500 cph (chips per hour) (Productivity priority mode) per module, a 44% improvement from the fastest speed of the NXT II.

0201 mm Part Support, +/- 0.025 mm Placing Accuracy
As well as supporting the smallest parts currently being used in mass production (0402 mm, 01005"), the NXT III can also handle the next generation of components heading for the market - 0201 mm parts.

By improving machine rigidity and further refining its independent servo control and vision recognition technology, Fuji has achieved a placing accuracy for small chip parts of +/- 0.025 mm* (3sigma, Cpk≥1.00).

Improved Usability
The GUI of the original NXT was widely praised for making use of intuitive and easy-to-understand pictograms instead of relying on language-based instructions.

This interface is now combined with a touchscreen panel to make operation even easier. This reduces the number of button pushes required and makes selecting commands easier, as well as improving quality by reducing the chance of performing the wrong command.

High Compatibility
Many of the main units from the NXT II such as placing heads, nozzle stations, feeders, tray units, and feeder pallet exchange units can be used on the NXT III without any modifications.

FUJI NXT III Scalable Placement Platforms Picture Show:







EXHIBITION:


SMT LINE:
