SMT Placement Solution Smd Mounting Machine Yamaha Σ-F8S Premium Modular Led Pick and Place Machine For SMT Assembly Line SMT Machine Line

Yamaha Σ-F8S Premium Modular For SMT Machine Line

Model:Σ-F8S

Applicable PCB(Single lane) :L330 x W250 to L50 x W50mm/(Option : L381 x W510 to L50 x W50mm)

Applicable PCB(Dual lane):L330 x W250 to L50 x W50mm

Head/Applicable components(High-speed head):0201mm CHIP to 4.3 x 3.4mm, Height 2.0mm or less

Head/Applicable components(High-speed multi-purpose head):03015mm CHIP to 33mm square, Height 12.7mm or less

Mounting capability(High-speed head x 4 specs):150,000CPH (Dual lane)/136,000CPH (Single lane)

Mounting accuracy(High-speed head):0201mm/03015mm : ±25μm (3σ) (140,000CPH) 0402mm/0603mm : ±36μm (3σ) (150,000CPH)

Number of component types:Max.80 types (conversion for 8mm tape feeder)

Power supply:3-Phase AC200V ±10% 50/60Hz

Air supply source:0.45 to 0.69MPa (4.6 to 7kgf/cm2)

External dimension:L 1,280 x W 2,240 x H 1,450mm (excluding projections)

Weight:Approx. 1,940kg

Product Description

SMT Placement Solution Smd Mounting Machine Yamaha Σ-F8S Premium Modular Led Pick and Place Machine For SMT Assembly Line SMT Machine Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

Yamaha Σ-F8S Premium Modular Technical Parameters :

Model	Σ-F8S
Applicable PCB	Single lane : L330 x W250 to L50 x W50mm (Option : L381 x W510 to L50 x W50mm) Dual lane : L330 x W250 to L50 x W50mm
Head/Applicable components	High-speed head : 0201mm CHIP to 4.3 x 3.4mm, Height 2.0mm or less High-speed multi-purpose head : 03015mm CHIP to 33mm square, Height 12.7mm or less
Mounting capability	High-speed head x 4 specs : 150,000CPH (Dual lane) 136,000CPH (Single lane)
Mounting accuracy (Under optimum conditions as defined by Yamaha Motor when standard evaluation materials are used)	High-speed head : 0201mm/03015mm : ±25μm (3σ) (140,000CPH) 0402mm/0603mm : ±36μm (3σ) (150,000CPH)
Number of component types	Max.80 types (conversion for 8mm tape feeder)
Power supply	3-Phase AC200V ±10% 50/60Hz
Air supply source	0.45 to 0.69MPa (4.6 to 7kgf/cm2)
External dimension	L 1,280 x W 2,240 x H 1,450mm (excluding projections)
Weight	Approx. 1,940kg

Yamaha Σ-F8S Premium Modular Details:

Feature
▶The "1-head solution" rotary head provides. Speed, versatility and high operating ratio.
▶Fastest speed in its class! Produces 150,000 CPH with 4-beam & 4-head.
▶Direct drive head gives high-speed & high-accuracy.
▶The Super Loading Feeder totally innovates components supply tasks!

Yamaha Σ-F8S Premium Modular Picture Show:
