HELLER 1809 MK5 Solder Reflow Oven SMT Reflow Oven For SMT Machine Line

Mode:1809 MK5 (Air)

Power Input (3 Phase) Standard:480 volts

KW:8.5 – 16 Continuous

Typical Run Current:25 – 35 amps @ 480v

Optional Power Inputs Available:208/240/380/400/415/440/480 VAC

Frequency:50/60 Hz

Overall Oven Dimensions:183″ (465cm) L x 60”(152cm) W x 63”(160cm) H

Typical Net Weight:4343 lbs. (1970 kg)

Typical Shipping Weight:5335 lbs. (2420 kg)

Typical Shipping Dimension:195” x 73” x 81”

Height From Floor:37.5″ + 2.4″ (95 cm + 6 cm)

Max. PCB Width:22″ (56 cm)

Mini./Max. Board Width:2″ – 22″ (5 – 56 cm) 24” (61cm) Optional**

Top & Bottom:9

Accuracy of Temperature Controller:+ .1°C

Cross-Belt Temperature Tolerance:+ 2.0°C

Heater Wattage Per Zone:5400 w***

Temperature Range Standard:60-350°C

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

  • SMT machine line  customer

HELLER 1809 MK5 SMT Reflow Oven Reflow Oven PCB Reflow Oven Reflow Soldering Oven Reflow Solder Oven Solder Reflow Oven For SMT Machine Line SMT Assembly Line

Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15

Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322

WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .

Also can support some original parts of machine repair.

Successful Experience:

1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World

2. Training More Than 500 Experts and Technician for Customers.

3. Became the Most Reliable Chinese Partner for You.

For SMT Factory Setup, We Can Do for You:

1. We Provide Full SMT Solution for You

2. We Provide Core Technology With Our Equipments

3. We Provide The Most Professional Tech Service

4. We Have Wealthy Experience on SMT Factory Setup

HELLER 1809 MK5 Solder Reflow Oven Technical Parameters :

MODEL

1809 MK5 (Air)

1809 MK5 (Nitrogen)

Electric Supply

Power Input

(3 Phase) Standard

480 volts

480 volts

KW

8.5 – 16 Continuous

7.5 – 16 Continuous

Typical Run Current

25 – 35 amps @ 480v

25 – 35 amps @ 480v

Optional Power Inputs Available

208/240/380/400/415/440/480 VAC

208/240/380/400/415/440/480 VAC

Frequency

50/60 Hz

50/60 Hz

Sequential Zone Turn On

S

S

Dimensions

Overall Oven Dimensions

183″ (465cm) L x 60” (152cm) W x 63” (160cm) H

183″ (465cm) L x 60” (152cm) W x 63” (160cm) H

Typical Net Weight

4343 lbs. (1970 kg)

4550 lbs. (2060 kg)

Typical Shipping Weight

5335 lbs. (2420 kg)

5556 lbs. (2520 kg)

Typical Shipping Dimension

195” x 73” x 81”

495 x 185 x 205 cm

Computer Control

AMD or Intel Based Computer

S

S

Flat Screen Monitor w/Mount

S

S

Windows Operating System

Windows 10 Home

Windows 10 Home

Auto Start Software

S

S

Data Logging

S

S

Password Protection

S

S

LAN Networking

O

O

Inert Atmosphere

Minimum PPM Oxygen

10-25 PPM*

Waterless Cooling w/ Flux Separation System

O

Nitrogen On/Off Valve

O

Oxygen Monitoring System

O

Nitrogen Standby System

O

Typical Nitrogen Consumption

500 – 700 SCFH **

Additional Features

KIC Profiling Software

S

S

Signal Light Tower

S

S

Powered Hood Lift

S

S

Five (5)Thermocouple Profiling

S

S

Redundant Alarm Sensors

O

O

Intelligent Exhaust System

O

O

KIC Profiler / ECD Profiler

O

O

Center Board Support

O

O

Board Drop Sensor

O

O

Board Counter

O

O

Barcode Reader

O

O

Custom Paint & Decal

O

O

Battery Backup for Conveyor and PC

O

O

GEM/SECS Interfacing

O

O

*May require additional hardware to achieve these levels ** Varies with PPM, PCB size and oven configuration Mesh Belt Conveyor

Height From Floor

37.5″ + 2.4″ (95 cm + 6 cm)

37.5″ + 2.4″ (95 cm + 6 cm)

Maximum PCB Width

22″ (56 cm)

22″  (56 cm)

Space Required Between PCBs

0.0″ (0.0 cm)

0.0″ (0.0 cm)

Conveyor Length On-Load

18″ (46 cm) *

3″ (7.5 cm) *

Conveyor Length Off-Load

18″ (46 cm) *

3″ (7.5 cm)  *

Heated Tunnel Length

101″ (256 cm)

101″  (256 cm

Process Clearance Above Mesh Belt

2.3″ (5.8 cm)

2.3″ (5.8 cm)

Mesh Belt Pitch

0.5″ (1.27 cm)

0.5″ (1.27 cm)

Maximum Conveyor Speed

74″/Min (188 cm/min.)

74″/Min (188 cm/min.)

Conveyor Direction Left to Right

S

S

Conveyor Direction Right to Left

O

O

Conveyor Speed Control

Closed Loop

Closed Loop

Edge Hold Conveyor System Option

Height from Floor – Standard

38.6″ + 2.4″ (98 cm + 6 cm)

 38.6″ + 2.4″ (98 cm + 6 cm)

Height from Floor – Optional1.15″ (2.9 cm)

  35.4″ + 2.4″ (90 cm + 6 cm)

  35.4″ + 2.4″ (90 cm + 6 cm)

 Clearance Above & Below Conveyor Pins

 1.15″ (2.9 cm)

 1.15″ (2.9 cm)

 Length of PCB Support Pins

 .187″ (4.75 mm)

 .187″ (4.75 mm)

 3 mm long support pins

 O

 O

Minimum/Maximum Board Width

2″ – 22″ (5 – 56 cm) 24” (61cm) Optional**

2″ – 22″ (5 – 56 cm) 24” (61cm) Optional**

Power Width Adjustment

S

S

Computer Controlled Width Adjust

O

O

Auto Lubrication System

S

S

Forced Heating Zones

Top & Bottom

9

9

Heater Type

Instant response open coil

Instant response open coil

Heater Material

Nichrome

Nichrome

Profile Change Time

5 – 15 minutes

5 – 15 minutes

Temperature Control

Accuracy of Temperature Controller

+ .1°C

+ .1°C

Cross-Belt Temperature Tolerance

+ 2.0°C

+ 2.0°C

Heater Wattage Per Zone

5400 w***

5400 w***

Temperature Range Standard

60-350°C

60-350°C

High Temperature Up to 450°C

O

O

Cooling Systems

Number of Cooling Zones Standard

2

2

Additional Cooling Zones

O

O

Water Cooling

O

Notes: S = Standard, O = Optional. * A 12″ (30 cm) Conveyor extension is an available option ** Need some SPL design *** 380V heater wattage 4400 W Specifications continue on reverse. A continuous program of product improvement may result in changes to specification and performance. The right is reserved to institute these improvements without notice or liability. April 2018

HELLER 1809 MK5 Solder Reflow Oven Details:

The 1800 reflow oven models support high mix / high volume throughput… at speeds up to 32 inches (80 centimeters) per minute, while conserving valuable factory floor space. Rapid response times and precise temperature controls assure process uniformity, regardless of component density or board loading, with identical profile performance in either air or nitrogen.
Features
1.Highest Yields and Tight Process Control
2.Wide Process Window for “Universal Profiling
3.Advanced 5 Thermocouple PCB Profiling and Process Parameter Logging Capability
4.New Flux System Eliminates Maintenance
5.Enhanced Heater Modules
6.Ultra-Parallel Conveyor System
7.Fastest Cooling Rates
8.Lead Free Certified
9.Ultra fast cooling rates of 3-5 Degrees/Second to form perfect grain structure.
10.More heated zones than any other competitor to allow “Profile Sculpting”.
11.Lowest Cost of Ownership

HELLER 1809 MK5 Solder Reflow Oven Picture Show:
