Heller 1707 MK5 Reflow Oven SMT Reflow Oven
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
Heller 1707 MK5 Reflow Oven SMT Reflow Oven Technical Parameters :
Dimensions
1707 MK5
Overall Length
142″ (3.6m)
# of Heat Zones
7
# of Cool Zones
1 Top (std.) Bottom Cool/External Cool optional
Max PCB Width
22″
Electric Supply
1707 MK5 (Air)
1707 MK5 (Nitrogen)
Power Input (3 Phase) Standard
480 volts
480 volts
Breaker Size
100 amps @ 480v
100 amps @ 480v
kW
7 – 12 Continuous
7 – 12 Continuous
Typical Run Current
20 – 30 amps @ 480v
20 – 30 amps @ 480v
Optional Power Inputs Available
208/240/380/400/415/440/480 VAC
208/240/380/400/415/440/480 VAC
Frequency
50/60 Hz
50/60 Hz
Sequential Zone Turn On
S
S
Dimensions
Overall Oven Dimensions
142″ (360cm) L x 60”(152cm) W x 63” (160cm) H
142″ (360cm) L x 60”(152cm) W x 63” (160cm) H
Typical Net Weight
3417 lbs. (1550kg)
3637 lbs. (1650 kg)
Typical Shipping Weight
4034 lbs. (1830 kg)
4520 lbs. (2050 kg)
Typical Shipping Dimension
146” x 73” x 81”
370 x 185 x 205cm
Computer Control
AMD or Intel Based Computer
S
S
Flat Screen Monitor w/Mount
S
S
Windows Operating System
Windows 10Ò Home
Windows 10Ò Home
Auto Start Software
S
S
Data Logging
S
S
Password Protection
S
S
LAN Networking
O
O
Inert Atmosphere
Minimum PPM Oxygen
–
10-25 PPM*
Waterless Cooling w/ Flux Separation System
–
O
Nitrogen On/Off Valve
–
O
Oxygen Monitoring System
–
O
Nitrogen Standby System
–
O
Typical Nitrogen Consumption
–
500 – 700 SCFH **
Additional Features
KIC Profiling Software
S
S
Signal Light Tower
S
S
Powered Hood Lift
S
S
Five (5)Thermocouple Profiling
S
S
Redundant Alarm Sensors
O
O
Intelligent Exhaust System
O
O
KIC Profiler / ECD Profiler
O
O
Center Board Support
O
O
Board Drop Sensor
O
O
Board Counter
O
O
Bar Code Reader
O
O
Custom Paint & Decal
O
O
Battery Backup for Conveyor and PC
O
O
GEM/SECS Interfacing
O
O
*May require additional hardware to achieve these levels ** Varies with PPM, PCB size and oven configuration Mesh Belt Conveyor
Height From Floor
37.5″ + 2.4″ (95 cm + 6 cm)
37.5″ + 2.4″ (95 cm + 6 cm)
Maximum PCB Width
22″ (56 cm)
22″ (56 cm)
Space Required Between PCBs
0.0″ (0.0 cm)
0.0″ (0.0 cm)
Conveyor Length On-Load
18″ (46 cm) *
3″ (7.5 cm) *
Conveyor Length Off-Load
18″ (46 cm) *
3″ (7.5 cm) *
Heated Tunnel Length
75″ (190 cm)
75″ (190 cm)
Process Clearance Above Mesh Belt
2.3″ (5.8 cm)
2.3″ (5.8 cm)
Mesh Belt Pitch
0.5″ (1.27 cm)
0.5″ (1.27 cm)
Maximum Conveyor Speed
74″/Min (188 cm/min.)
74″/Min (188 cm/min.)
Conveyor Direction Left to Right
S
S
Conveyor Direction Right to Left
O
O
Conveyor Speed Control
Closed Loop
Closed Loop
Edge Hold Conveyor System Option
Height from Floor – Standard
38.6″ + 2.4″ (98 cm + 6 cm)
38.6″ + 2.4″ (98 cm + 6 cm)
Height from Floor – Optional
35.4″ + 2.4″ (90 cm + 6 cm)
35.4″ + 2.4″ (90 cm + 6 cm)
Clearance Above & Below Conveyor Pins
1.15″ (2.9 cm)
1.15″ (2.9 cm)
Length of PCB Support Pins
.187″ (4.75 mm)
.187″ (4.75 mm)
3 mm long support pins
O
O
Minimum/Maximum Board Width
2″ – 22″ (5 – 56 cm) 24” (61cm) Optional**
2″ – 22″ (5 – 56 cm) 24” (61cm) Optional**
Power Width Adjustment
S
S
Computer Controlled Width Adjust
O
O
Auto Lubrication System
S
S
Forced Convection Zones
Top & Bottom
7
7
Heater Type
Instant response open coil
Instant response open coil
Heater Material
Nichrome
Nichrome
Profile Change Time
5 – 15 minutes
5 – 15 minutes
Temperature Control
Accuracy of Temperature Controller
+ .1°C
+ .1°C
Cross-Belt Temperature Tolerance
+ 2.0°C
+ 2.0°C
Heater Wattage Per Zone
5400 w***
5400 w***
Temperature Range Standard
60-350°C
60-350°C
High Temperature Up to 450°C
O
O
Cooling Systems
Number of Cooling Zones Standard
1
1
Additional Cooling Zones
0
0
Water Cooling
–
1
Notes: S = Standard, O = Optional. * A 12″ (30 cm) Conveyor extension is an available option ** Need some SPL design *** 380V heater wattage 4400 W Specifications continue on reverse. A continuous program of product improvement may result in changes to specification and performance. The right is reserved to institute these improvements without notice or liability.
Our most popular convection reflow oven series, The Heller 1707 series supports high mix / medium volume throughput at speeds up to 24 inches (60 centimetres) per minute. Rapid response times and precise temperature controls guarantee process uniformity, regardless of component density or board loading, with identical profile performance in either air or nitrogen.
Features
- Highest Yields and Tight Process Control
- Wide Process Window for “Universal Profiling”
- Advanced 5 Thermocouple PCB Profiling and Process Parameter Logging Capability
- New Flux System Eliminates Maintenance
- Enhanced Heater Modules
- Ultra-Parallel Conveyor System
- Fastest Cooling Rates
- Lead Free Certified
- “Spike Zone” design to minimize liquidous time.
- Ultra fast cooling rates of 3-5 Degrees/Second to form perfect grain structure.
- More heated zones than any other competitor to allow “Profile Sculpting”
Heller 1707 MK5 Reflow Oven SMT Reflow Oven Picture Show:
