HELLER 1707 MK III SMT Reflow Oven Reflow Oven PCB Reflow Oven Reflow Soldering Oven Reflow Solder Oven Solder Reflow Oven For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
HELLER 1707 MK III Solder Reflow Oven Technical Parameters :
|
MODEL |
1707 MKIII (Air) |
1707 MKIII (Nitrogen) |
|
Electric Supply |
||
|
Power Input(3 Phase)Standard |
208/240 volts |
208/240 volts |
|
Breaker Size |
100 amps @208v |
100 amps @208v |
|
kW |
7-14 Continuous |
7-14 Continuous |
|
Typical Run Current |
30-35 amps @208v |
30-35 amps @208v |
|
Optional Power Inputs Available |
208/240/380/400/415 VAC |
208/240/380/400/415 VAC |
|
Frequency |
50/60 Hz |
50/60 Hz |
|
Sequential Zone Turn On |
S |
S |
|
Dimensions |
||
|
Overall Oven Dimensions |
134"(340cm)L x56"(142cm)W x63”(160cm)H |
134"(340cm)L x56"(142cm)W x63”(160cm)H |
|
Typical Net Weight |
3550 lbs. (1610 kg) |
3630 lbs. (1650 kg) |
|
Typical Shipping Weight |
4400lbs. (1990 kg) |
4510 lbs. (2050 kg) |
|
Typical Shipping Dimension |
146”x73”x81” |
370x185x205cm |
|
Computer Control |
||
|
AMD or Intel Based Computer |
S |
S |
|
Flat Screen Monitor w/Mount |
S |
S |
|
Windows Operating System |
Windows 8R Home Premium |
Windows 8R Home Premium |
|
Auto Start Software |
S |
S |
|
Data Logging |
S |
S |
|
Password Protection |
S |
S |
|
LAN Networking |
0 |
0 |
|
Inert Atmosphere |
||
|
Minimum PPM Oxygen |
- |
10-25 PPM* |
|
Waterless Cooling w/
Flux Separation System
|
- |
0 |
|
Nitrogen On/Off Valve |
- |
0 |
|
Oxygen Monitoring System |
- |
0 |
|
Nitrogen Standby System |
- |
0 |
|
Typical Nitrogen Consumption |
- |
500-700 SCFH** |
|
Additional Features |
||
|
KIC Profiling Software |
S |
S |
|
Signal Light Tower |
S |
S |
|
Powered Hood Lift |
S |
S |
|
Five (5)Thermocouple Profiling |
S |
S |
|
Redundant Alarm Sensors |
0 |
0 |
|
Intelligent Exhaust System |
0 |
0 |
|
KIC Profiler/ECD Profiler |
0 |
0 |
|
Center Board Support |
0 |
0 |
|
Board Drop Sensor |
0 |
0 |
|
Board Counter |
0 |
0 |
|
Bar Code Reader |
0 |
0 |
|
Custom Paint &Decal |
0 |
0 |
|
Battery Backup for Conveyor and PC |
0 |
0 |
|
GEM/SECS Interfacing |
0 |
0 |
|
*Mav reauire additional hardware to achieve these levels**Varies with PPM PCR size and oven confioiration |
||
|
Mesh Belt Conveyor |
||
|
Height From Floor |
35.5"±2.0"(90 cm±5 cm) |
35.5"±2.0"(90 cm±5 cm) |
|
Maximum PCB Width
**Requires wider heat modules
|
18“(56 cm)/22”(56cm)** |
18“(56 cm)22”(56 cm)** |
|
Space Required Between PCB's |
0.0"(0.0 cm) |
0.0"(0.0 cm) |
|
Conveyor Length On-Load |
18"(46 cm)* |
3"(7.5 cm)* |
|
Conveyor Length Off-Load |
18"(46 cm)* |
3"(7.5 cm)* |
|
Heated Tunnel Length |
70"(179 cm) |
70"(179 cm) |
|
Process Clearance Above Mesh Belt |
2.3"(5.8 cm) |
2.3"(5.8 cm) |
|
Mesh Belt Pitch |
0.5"(1.27 cm) |
0.5"(1.27 cm) |
|
Maximum Conveyor Speed |
74"/Min(188 cm/min.) |
74"/Min(188 cm/min.) |
|
Conveyor Direction Left to Right |
S |
S |
|
Conveyor Direction Right to Left |
0 |
0 |
|
Conveyor Speed Control |
Closed Loop |
Closed Loop |
|
Edge Hold Conveyor System Option |
|
|
|
Height from Floor-Standard |
37.0"±2.0"(94 cm±5 cm) |
37.0"±2.0"(94 cm±5 cm) |
|
Height from Floor-Optional |
32.6"+3.9"/-.4"
(83 cm+10 cm/-1 cm)
|
32.6"+3.9"/-.4"
(83 cm+10 cm/-1 cm)
|
|
Clearance Above &Below Conveyor Pins |
1.15"(2.9 cm) |
1.15"(2.9 cm) |
|
Length of PCB Support Pins |
187"(4.75 mm) |
187"(4.75 mm) |
|
3 mm long support pins |
0 |
0 |
|
Minimum/Maximum Board Width |
2.0"-18"(5-46 cm)
22”(56cm)optional
|
2.0"-18"(5-46 cm)
22”(56cm)optional
|
|
Power Width Adjustment |
S |
S |
|
Computer Controlled Width Adjust |
0 |
0 |
|
Auto Lubrication System |
0 |
0 |
|
Forced Convection Zones |
|
|
|
Top &Bottom |
7 |
7 |
|
Heater Type |
Instant response open coil |
Instant response open coil |
|
Heater Material |
Nichrome |
Nichrome |
|
ProfileChange Time |
5-15 minutes |
5-15 minutes |
|
Temperature Control |
|
|
|
Accuracy of Temperature Controller |
±.1℃ |
±.1℃ |
|
Cross-Belt Temperature Tolerance |
±2.0℃ |
±2.0℃ |
|
Heater Wattage Per Zone |
6000 w** |
6000 w** |
|
Temperature Range Standard |
60-350℃ |
60-350℃ |
|
High Temperature Up to 450℃ |
0 |
0 |
|
Cooling Systems |
|
|
|
Number of Cooling Zones Standard |
1 |
1 |
|
Additional Cooling Zones |
0 |
0 |
|
Water Cooling |
- |
0 |
|
Notes:S=Standard,O=Optional.*A12"(30 cm)Conveyor extension is an available option **380Vheater watage 4800
Specifications continue on reverse.
|
||
Process Control
In addition to PID controllers used to monitor and adjust the oven temperatures, the 1707 MKIII has process control software powered by ECD (home of M.O.L.E. thermal profilers). Oven and Process Cpk are tracked, and product traceability is reported.
Conveyor System
Both an edge hold conveyor and a mesh belt conveyor are part of the two-fold conveyor system in the 1707 MKIII. The edge hold can support a PCB assembly with as little as 3(mm) edge clearance, and the mesh belt does not require space between the PCB assemblies.
Heating Modules
Accuracy of the temperature controller is plus or minus 0.1 degrees Celsius and cross-belt tolerance is within plus or minus 3.0 degrees Celsius. These tight temperature ranges are accomplished using Nichrome heater material and calcium silicate insulation.
Cooling Module
A “blow thru” cooling module is used in the final cooling zone to provide cooling rates greater than 3 degrees Celsius per second on even the largest land grid array components.
HELLER 1707 MK III Solder Reflow Oven Picture Show:
