HELLER 1936 MKV SMT Reflow Oven Reflow Oven PCB Reflow Oven Reflow Soldering Oven Reflow Solder Oven Solder Reflow Oven For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
HELLER 1936 MKV Solder Reflow Oven Technical Parameters :
Model
1936 MKV (Air)
1936 MKV (Nitro)
Electric Supply
Power Input (3 Phase)Standard
480 volts
480 volts
Breaker Size
100 amps @480v
100 amps @480v
kW
9-15 Continuous
9-15 Continuous
Typical Run Current
30-35 amps @480v
30-35 amps@,480v
Optional Power Inputs Available
208/240/380/400/415 VAC
208/240/380/400/415 VAC
Frequency
50/60 Hz
50/60 Hz
Sequential Zone Turn On
S
S
Dimensions
Overall Oven Dimensions
232"(590cm)L x60”(152cm)W x63"(160cm)H
232"(590cm)L x60”(152cm)Wx63"(160cm)H
Typical Net Weight
6380 lbs. (2900 kg)
7180 lbs. (3280 kg)
Typical Shipping Weight
78751bs. (3580 kg)
8980 lbs. (4080 kg)
Typical Shipping Dimension
244”x73”x83”
620x185x210 cm
Computer Control
AMD or Intel Based Computer
S
S
Flat Screen Monitor w/Mount
S
S
Windows Operating System
Windows 7R Home Premium
Windows 7B Home Premium
Auto Start Software
S
S
Data Logging
S
S
Password Protection
S
S
LAN Networking
0
0
Inert Atmosphere
Minimum PPM Oxygen
10-25 PPM*
0
Nitrogen On/Off Valve
0
Oxygen Monitoring System
0
Nitrogen Standby System
0
Typical Nitrogen Consumption
500-700 SCFH**
Additional Features
KIC Profiling Software
S
S
Signal Light Tower
S
S
Powered Hood Lift
S
S
Five (5)Thermocouple Profiling
S
S
Redundant Alarm Sensors
0
0
Intelligent Exhaust System
0
0
KIC Profiler/ECD Profiler
0
0
Center Board Support
0
0
Board Drop Sensor
0
0
Board Counter
0
0
Bar Code Reader
0
0
Custom Paint &Decal
0
0
Battery Backup for Conveyor and PC
0
0
GEM/SECS Interfacing
0
0
*May require additional hardware to achieve these levels **Varies with PPM,PCB size and oven configuration
Mesh Belt Conveyor
Height From Floor
35.5"±2.0"(90 cm±5 cm)
35.5"±2.0"(90 cm±5 cm)
Maximum PCB Width
22"(55 cm)
22"(56 cm)
Space Required Between PCB's
0.0"(0.0 cm)
0.0"(0.0 cm)
Conveyor Length On-Load
18"(46 cm)*
3"(7.5 cm)*
Conveyor Length Off-Load
18"(46 cm)*
3"(7.5 cm)*
Heated Tunnel Length
135"(343 cm)
135"(343 cm)
Process Clearance Above Mesh Belt
2.3"(5.8 cm)
2.3"(5.8 cm)
Mesh Belt Pitch
0.5"(1.27 cm)
0.5"(1.27 cm)
Maximum Conveyor Speed
74"/Min(188 cm/min.)
74"/Min(188 cm/min.)
Conveyor Direction Left to Right
S
S
Conveyor Direction Right to Left
0
0
Conveyor Speed Control
Closed Loop
Closed Loop
Edge Hold Conveyor System Option
Height from Floor-Standard
37.0"±2.0"(94 cm±5 cm)
37.0"±2.0"(94 cm±5 cm)
Height from Floor-Optional
Clearance Above &Below Conveyor Pins
1.15"(2.9 cm)
1.15"(2.9 cm)
Length of PCB Support Pins
187"(4.75 mm)
.187"(4.75 mm)
3 mm long support pins
0
0
Minimum/Maximum Board Width
2.0"-22"(5-56 cm)
2.0"-22"(5-56 cm)
Power Width Adjustment
S
S
Computer Controlled Width Adjust
0
0
Auto Lubrication System
0
0
Forced Convection Zones
Top &Bottom
10
10
Heater Type
Instant response open coil
Instant response open coil
Heater Material
Nichrome
Nichrome
Profile Change Time
5-15 minutes
5-15 minutes
Temperature Control
Accuracy of Temperature Controller
±.1℃
+.1°C
Cross-Belt Temperature Tolerance
+2.0℃
+2.0℃
Heater Wattage Per Zone
6000 w**
6000 w**
Temperature Range Standard
60-350℃
60-350℃
High Temperature Up to 450℃
0
0
Cooling Systems
Number of Cooling Zones Standard
3
3
Additional Cooling Zones
0
0
Water Cooling
0
Notes:S=Standard,O=Optional.*A12"(30 cm)Conveyor extension is an available option **380V heater wattage 4800 Specifications continue on reverse.
HELLER 1936 MKV Solder Reflow Oven Details:
Heller has designed and built an production ready horizontal reflow oven for formic acid vapor. This new oven has been designed to meet Semi S2/S8 safety standards (including toxic gases).
- Formic Acid has been shown to be an effective reducing agent in fluxless solder reflow
- Excellent results demonstrated for wafer bumping application in horizontal reflow oven
- Fluxless reflow utilizes gas phase Formic Acid (HCOOH) to replace standard fluxing agents
- Eliminates the need for pre-reflow fluxing and post-reflow flux cleanup steps
- No post-reflow flux clean facilitates inline application of epoxy and inline epoxy curing solution
- Feasibility has been demonstrated with production grade oven
- Extensive engineering efforts in safe, precision delivery of formic acid and abatement
Fluxless Reflow Advantages
- Can use any reflow profile (e.g., tent or soak profile) with formic acid
- Can adjust formic acid profile in oven in conjunction with thermal reflow profile
- Includes Formic acid safety system (i.e., sensors/detectors) adheres to industry standards
- Includes Formic acid abatement systems for Green Process Solution
- Includes real time formic acid concentration monitor system
HELLER 1936 MKV Solder Reflow Oven Picture Show:
Exhibition:
SMT LINE:
