HELLER 1936 MK7 SMT Reflow Oven Reflow Oven PCB Reflow Oven Reflow Soldering Oven Reflow Solder Oven Solder Reflow Oven For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
HELLER 1936 MK7 Solder Reflow Oven Technical Parameters :
Model
1936MK7 (Air)
1936MK7 (Nitro)
Electric Supply
Power Input (3 Phase) Standard
480 volts
480 volts
Breaker Size
100 amps @ 480v
100 amps @ 480v
kW
9 - 15 Continuous
9 - 15 Continuous
Typical Run Current
25 - 35 amps @ 480v
25 - 35 amps @ 480v
Optional Power Inputs Available
208/240/380/400/415/440/480 VAC
208/240/380/400/415/440/480 VAC
Frequency
50/60 Hz
50/60 Hz
Sequential Zone Turn On
S
S
Dimensions
Overall Oven Dimensions
232" (590cm) L x 60" (152cm) W x57" (144cm) H
232" (590cm)Lx60"(152cm)Wx57" (144cm) H
Typical Net Weight
4674 lbs. (2120 kg)
5560 lbs. (2520 kg)
Typical Shipping Weight
6064 lbs. (2740 kg)
6928 lbs. (3140 kg)
Typical Shipping Dimension
620 x 185 x 185 cm
620 x 185 x 185 cm
Computer Control
AMD or Intel Based Computer
S
S
Flat Screen Monitor w/Mount
S
S
Windows Operating System
Windows 10 Home
Windows 10 Home
Auto Start Software
S
S
Data Logging
S
S
Password Protection
S
S
LAN Networking
O
O
Inert Atmosphere
Minimum PPM Oxygen
-
10-25 PPM*
Waterless Cooling w/ Flux
Separation System
-
O
Nitrogen On/Off Valve
-
O
Oxygen Monitoring System
-
O
Nitrogen Standby System
-
O
Typical Nitrogen Consumption
-
500 - 700 SCFH **
Additional Features
KIC Profiling Software
S
S
Signal Light Tower
S
S
Powered Hood Lift
S
S
Five (5)Thermocouple Profiling
S
S
Redundant Alarm Sensors
O
O
Intelligent Exhaust System
O
O
KIC Profiler / ECD Profiler
O
O
Center Board Support
O
O
Board Drop Sensor
O
O
Board Counter
O
O
Bar Code Reader
O
O
Custom Paint & Decal
O
O
Battery Backup for Conveyor and PC
O
O
GEM/SECS Interfacing
O
O
Mesh Belt Conveyor
Height From Floor
36.6" + 2.4" (93 cm + 6 cm)
36.6" + 2.4" (93 cm + 6 cm)
Maximum PCB Width
22" (56 cm)
22" (56 cm)
Space Required Between PCB's
0.0" (0.0 cm)
0.0" (0.0 cm)
Conveyor Length On-Load
18" (46 cm) *
3" (7.5 cm) *
Conveyor Length Off-Load
18" (46 cm) *
3" (7.5 cm) *
Heated Tunnel Length
140" (355 cm)
140" (355 cm)
Process Clearance Above Mesh Belt
2.3" (5.8 cm)
2.3" (5.8 cm)
Mesh Belt Pitch
0.5" (1.27 cm)
0.5" (1.27 cm)
Maximum Conveyor Speed
74"/Min (188 cm/min.)
74"/Min (188 cm/min.)
Conveyor Direction Left to Right
S
S
Conveyor Direction Right to Left
O
O
Conveyor Speed Control
Closed Loop
Closed Loop
Edge Hold Conveyor System Option
Height from Floor - Standard
37.8" ±2.4" (96 cm ± 6 cm)
37.8" ±2.4" (96 cm ± 6 cm)
Height from Floor - Optional
35.4" ± 2.4"
35.4" ± 2.4"
(90 cm ± 6 cm)
(90 cm ± 6 cm)
Clearance Above & Below Conveyor Pins
1.15" (2.9 cm)
1.15" (2.9 cm)
Length of PCB Support Pins
.187" (4.75 mm)
.187" (4.75 mm)
3 mm long support pins
O
O
Minimum/Maximum Board Width
2" - 22" (5 - 56 cm)
2" - 22" (5 - 56 cm)
24" (61cm) Optional**
24" (61cm) Optional**
Power Width Adjustment
S
S
Computer Controlled Width Adjust
O
O
Auto Lubrication System
S
S
Forced Convection Zones
Top & Bottom
10
10
Heater Type
Instant response open coil
Instant response open coil
Heater Material
Nichrome
Nichrome
Profile Change Time
5 - 15 minutes
5 - 15 minutes
Temperature Control
Accuracy of Temperature Controller
± .1ºC
± .1ºC
Cross-Belt Temperature Tolerance
±3.0°C
±3.0°C
Heater Wattage Per Zone
5400 w***
5400 w***
Temperature Range Standard
60-350ºC
60-350ºC
High Temperature Up to 450ºC
O
O
Cooling Systems
Number of Cooling Zones Standard
3
3
Cooling zone Length
107cm
115cm
Additional Cooling Zones
O
O
Water Cooling
-
O
Notes:
S = Standard, O = Optional.
HELLER 1936 MK7 Solder Reflow Oven Details:
The 1936 MK7 is a high volume reflow oven system with 10 heated zones and belt speeds up to 1.88m/min. The 1936 MK7 offers the lowest delta T’s, reduced nitrogen and electrical consumption and advanced flux management options. The 12” wide heater modules offer profile compatibility with competitor systems.
Heller Industries has unveiled its latest innovation, the Heller MK7 Reflow Oven. This state-of-the-art reflow oven comes with a host of advanced features and cutting-edge technology, aimed at enhancing efficiency, precision, and sustainability in the production of electronic components.
The Next Evolution in Reflow Technology
The Heller MK7 Reflow Oven represents the next evolution in reflow technology, building upon the successes of its predecessors this oven addresses the ever-growing demands of the electronics industry. Designed with both productivity and sustainability in mind, the MK7 is set to become a favorite choice for manufacturers worldwide.
Key Features and Advantages
1.Smart Thermal Profiling: The MK7 oven is equipped with intelligent thermal profiling capabilities, enabling real-time adjustments to the temperature profile during the reflow process. This ensures optimal heat distribution and minimizes the risk of defects, resulting in higher-quality solder joints.
2.Eco-Friendly Design: In an era where environmental concerns are paramount, the Heller MK7 stands out with its eco-friendly design. The oven incorporates energy-efficient heating elements and advanced insulation materials, reducing power consumption and overall carbon footprint.
3.Enhanced User Interface: The Heller MK7 boasts a user-friendly interface, allowing operators to set up and monitor the reflow process with ease. Its intuitive controls and visual indicators enable quick and seamless operation, even for less-experienced personnel.
4.Advanced Conveyor System: The MK7 oven features a precision conveyor system, ensuring smooth and reliable movement of PCBs through the reflow process. This reduces the risk of misalignment or damage to delicate components, optimizing throughput and overall yield.
5.Industry 4.0 Integration: Embracing the concept of Industry 4.0, the Heller MK7 is equipped with smart connectivity options, enabling seamless integration with factory automation systems. This facilitates data exchange and provides valuable insights into production performance for better decision-making.
HELLER 1936 MK7 Solder Reflow Oven Picture Show:
Exhibition:
SMT LINE:
