HELLER 1913 MK5 SMT Reflow Oven Reflow Oven PCB Reflow Oven Reflow Soldering Oven Reflow Solder Oven Solder Reflow Oven For SMT Machine Line SMT Assembly Line
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
HELLER 1913 MK5 Solder Reflow Oven Technical Parameters :
MODEL
1913MKIII (Air)
1913MKIII (Nitrogen)
Electric Supply
Power Input(3 Phase)Standard
480 volts
480 volts
Breaker Size
100 amps @480v
100 amps @480v
kW
12-19 Continuous
12-19 Continuous
Typical Run Current
30-35 amps@480v
30-35 amps @480v
Optional Power Inputs Available
208/240/380/400/415VAC
208/240/380/400/415 VAC
Frequency
50/60 Hz
50/60 Hz
Sequential Zone Turn On
S
S
Dimensions
Overall Oven Dimensions
232"x54”x63"
589 cmx137 cm x 160 cm
Typical Net Weight
6380 lbs. (2900 kg)
6380 lbs. (2900 kg)
Typical Shipping Weight
7875 lbs. (3580 kg)
7475 lbs. (3680 kg)
Computer Control
AMD or Intel Based Computer
S
S
Flat Screen Monitor w/Mount
S
S
Windows Operating System
Windows Vista/7R
Windows Vista/7R
Auto Start Software
S
S
Data Logging
S
S
Password Protection
S
S
LAN Networking
0
0
Inert Atmosphere
Minimum PPM Oxygen
10-25 PPM
Waterless Cooling w/Flux
0
Nitrogen On/Off Valve
0
Oxygen Monitoring System
0
Nitrogen Standby System
0
Typical Nitrogen Consumption
500-700 SCFH*
Additional Features
KIC Profiling Software
S
S
Signal Light Tower
S
S
Powered Hood Lift
S
S
Five (5)Thermocouple Profiling
S
S
Redundant Alarm Sensors
0
0
Intelligent Exhaust System
0
0
KIC Profiler/ECD Profiler
0
0
Center Board Support
0
0
Board Drop Sensor
0
0
Board Counter
0
0
Bar Code Reader
0
0
Custom Paint &Decal
0
0
Battery Backup for Conveyor and PC
0
0
GEM/SECS Interfacing
0
0
Mesh Belt Conveyor
Height From Floor
35.5"±2.0"(90 cm±5 cm)
35.5"±2.0"(90 cm±5 cm)
Maximum PCB Width
10"(25 cm)15"(38 cm)18"(46 cm)
10"(25 cm)15"(38 cm)18"(46 cm)
Space Required Between PCB's
0.0"(0.0 cm)
0.0"(0.0 cm)
Conveyor Length On-Load
18"(46 cm)*
6"(15 cm)*
Conveyor Length Off-Load
18"(46 cm)*
6"(15 cm)*
Heated Tunnel Length
135"(343 cm)
135"(343 cm)
Process Clearance Above Mesh Belt
2.3"(5.8 cm)
2.3"(5.8 cm)
Mesh Belt Pitch
0.5"(1.27 cm)
0.5"(1.27 cm)
Maximum Conveyor Speed
74"/Min(188 cm/min.)
74"/Min(188 cm/min.)
Conveyor Direction Left to Right
S
S
Conveyor Direction Right to Left
0
0
Edge Hold Conveyor System Option
Height from Floor-Standard
37.0"±2.0"(94 cm±5 cm)
37.0"±2.0"(94 cm±5 cm)
Height from Floor-Optional
32.6"+3.9"/-.4"
32.6"+3.9"/-.4"
Clearance Above &Below Conveyor Pins
1.15"(2.9 cm)
1.15"(2.9 cm)
Length of PCB Support Pins
.187"(4.75 mm)
187"(4.75 mm)
3 mm long support pins
0
0
Minimum/Maximum Board Width
2.0"-24"*(5-61 cm)
2.0"-24"*(5-61 cm)
Power Width Adjustment
S
S
Computer Controlled Width Adjust
0
0
Auto Lubrication System
0
0
Forced Convection Zones
Top&Bottom
13
13
Heater Type
Instant response open coil
Instant response open coil
Heater Material
Nichrome
Nichrome
Profile Change Time
5-15 minutes
5-15 minutes
Temperature Control
Accuracy ofTemperature Controller
+.1C
+.1°C
Cross-Belt Temperature Tolerance
+2.0℃
+2.0℃
Heater Wattage Per Zone
6000w
6000w
Temperature Range Standard
65-350℃
65-350℃
High Temperature Up to 450℃
0
0
Cooling Systems
Number of Cooling Zones Standard
3
3
Bottom Cooling Zones
0
0
Water Cooling
0
External Cooling
0
0
Notes: S=Standard,O=Optional.*A 12"(30 cm)Conveyor extension is an available option
HELLER 1913 MK5 Solder Reflow Oven Details:
Separation System
20“(50 cm)22~24”(56~61 cm)*
20“(50 cm)22~24”(56~61 cm)*
(83 cm+10 cm/-1 cm)
(83 cm+10 cm/-1 cm)
(4 optional)
Our most popular convection reflow oven series
The ultimate high volume Surface Mount Technology production solution with belt speeds up to 1.4m/min to accommodate the fastest pick-and-place systems delivering the highest levels of repeatability with the lowest delta Ts.
Highest Yields and Tight Process Control
The most efficient heat transfer from extra high volume, high-velocity, heating modules, producing heater module response of less than one second to temperature changes of less than 0.1ºC, thereby maintaining profile integrity for heavy board loads.
Wide process window for “universal profiling” – allows many different boards to be run on a single temperature profile
Advanced 5 thermocouple PCB profiling and process parameter logging capability with the capacity to store up to 500 temperature recipes and 500 profile graphs
With a high-capacity, 26-inch wide heater module, the 1900 MkV Series reflow oven machine system offers unmatched flexibility in pcb board handling. The oven may be fitted with an adjustable single-rail edge hold conveyor/mesh belt combo, to carry even the largest boards or multi-board panels (up to 20 inches wide) through the oven.
HELLER 1913 MK5 Solder Reflow Oven Picture Show:
