Smt Assembly Line SMT Machine Hanwha SM481 Plus Pick and Place Machine
Whatsapp:+8613728632793, skype:Joaquin Xie,wechat:Joaquin15
Whatsapp:+8613424013606,skype:sensenhenhao,wechat:JoyLY0322
WE are smt support provider for smt machine parts and equipment .such as feeder,nozzle , feeder storage cart smt reel rack , smt grease , solder paste mixer, smd counter, KIC thermal profiler,smt tape and so on .
Also can support some original parts of machine repair.
Successful Experience:
1. We Have Been Helping Customers To Build a Lot of New Factories Around the World.Meraif's Customer In 35 Countries Around the World
2. Training More Than 500 Experts and Technician for Customers.
3. Became the Most Reliable Chinese Partner for You.
For SMT Factory Setup, We Can Do for You:
1. We Provide Full SMT Solution for You
2. We Provide Core Technology With Our Equipments
3. We Provide The Most Professional Tech Service
4. We Have Wealthy Experience on SMT Factory Setup
Hanwha SM482 Plus Pick and Place Machine Technical Parameters :
Hanwha SM482 Plus Pick and Place Machine Details:
Model
SM482 PLUS
Vision
Flying Vision + Stage Vision
Number of Head
6 Head x 1 Gantry
Placement Speed
30,000 CPH (Optimal)
Accuracy
Chip
±40μm@μ+3σ (Based on
the standard chips)
QFP
±30μm@μ+3σ (Based on
the standard chips)
Components Range
Flying Vision
FOV 16(option)
0402 (01005 inch) ~ 14mm IC, Connector (Lead Pitch 0.4mm)* BGA, CSP (Ball Pitch 0.65mm)
FOV 25(standard)
0603 (0201 inch) ~ 22mm IC, Connector (Lead Pitch 0.5mm)~ 17mm BGA, CSP (Ball Pitch 0.75mm)
Stage Vision
FOV 35(option)
~ 32mm IC, Connector (Lead Pitch 0.3mm)* BGA, CSP (Ball Pitch 0.5mm)~ 55mm (MFOV)
FOV 45(standard)
~ 42mm IC, Connector (Lead Pitch 0.4mm)* BGA, CSP (Ball Pitch 1.0mm)~ 55mm (MFOV), ~ □ 75mm Connector
Placement Height
15mm
PCB Dimension (LxW mm)
Min 50(L)x40(W)
50(L)x40(W)
Max
460(L) x 400(W)
510(L) x 460(W) (Option)
610(L) x 510(W) (Option)
1200(L) x 510(W) (Option)
PCB Thickness (mm)
0.38 - 4.2
Feeder Capacity (8mm standard)
120ea/112ea (Docking cart)
Utility
Power
AC 200 / 208 / 220 / 240 / 380 / 415 V(50/60Hz, 3Phase) Max. 4.7kVA
Air Conumption
0.5 ~ 0.7MPa (5 ~ 7kgf/cm²) 180Nℓ/min,50Nℓ/min (Vacuum Pump)
Weight (Kg)
± 1,600kg
External Dimension (LxDxH mm)
1,650(L) x 1,680(D) x 1,530(H)
SMT Pick and place machine from HANWHA - Formely Samsung Techwin.
Highly reliable SM482 PLUS is the latest generation of Full Vision pick and place machine from Hanwha.
Cost of ownership is extremely low due to the simple yet reliable X/Y/Z structure.
Easy to use software allows users to quckly learn the machine and get the most from it. Standard component library has more than 1800 shapes and the polygonic algorithm automatically detects component outlines on difficult components.
Features:
- Built in vacuum pump making air consumption just 50Nl/min!!!!
- Easily Identifieable Feeders
- Adaptive Pick Up
- Front and back operation as standard
- Large PCB Size of 460mm x 400mm as standard with optional size up to 1200mm length
- 0201 component recognition as standard with 01005 option
- 120 x 8mm Feeder Capacity
- High Accuracy ±30µ@3σ/QFP, ±40µ@3σ/Chip
- Small Footprint of just 1650mm x 1690mm x 1535mm
- 4.7KVA Max Power
Options:
- Intelligent Feeder System including Bar Code reading of PCB and parts, lot tracking
- SMART Feeder with Auto Splicing
- Docking Carts for Quick Job Change
- Various Large Board Options up to 1200mm length
- Safety Area Sensor
- UPS
- Tape Cutter Box
- Multi Storey Tray Feeders
Hanwha SM482 Plus Pick and Place Machine Picture Show:
